The PIC 18 PIN (DIP) Development / Evaluations Board demonstrates the capabilities of Microchip’s 8-bit microcontrollers, specifically, 18 Pin PIC16F1847. It can be used as a standalone demonstration board with a programmed part. With this board you can develop and prototype with all Microchip’s 18 PIN PIC microcontrollers. The board has a Reset switch and status LEDs. On board 3.3 V and 5V DC regulators allows using 3V and 5V PICs, This board support both 3.3V low power and normal 5V operation. All I/O Pins out with 2 x female headers

Development Board Features:

  • 16 I/O Ports
  • Onboard 5V and 3.3V Supply
  • 3.3V or 5V Supply selection by jumper
  • Dual line I/O
  • On board Power Indication
  • On-board ICSP Port (PICKIT2 Standard Programming Port)
  • Well labeled legends
  • All outputs has provision for LEDs for output indication
  • Replaceable PIC Microcontroller,
  • Crystal and capacitor mounting under the PCB

18 PIN PIC Development Board – [Link]
