Vicente Jiménez has published a new project. It’s a circuit probe that gives an indication when a node is floating or driven logic high or logic low and can also be used as a continuity tester. He writes:

Sometimes you need to check one circuit and test some of its nodes. Usually a tester in voltage mode is a good solution, but it has a pair of problems. First, it measures about zero both when the node is driven at zero volts and when the node is floating (not driven at all). Second, it gives the information on the tester display, so you need to take the view from the circuit to the tester to check the voltage.

Building a simple Circuit Probe – [Link]
