DC Servo Motor Driver – Analog Closed Loop Control

DC Servo Motor Driver – Analog Closed Loop Control

Versatile project has been designed to use in automotive application and industrial servo control application. This project provides all active necessary functions for closed loop servo system using Brushed DC Motor and potentiometer mounted on output shaft of DC Motor Gear. This project is ideally suited for almost any servo positioning application.

Features

  • POWER SUPPLY: 12-30V DC
  • MOTOR LOAD: 800mA MAX
  • P2: Position Potentiometer
  • P1: Fed Back potentiometer couple with DC Gear Motor output shaft
  • CN1: Power Input 12V-30V DC
  • Motor: DC Motor

DC Servo Motor Driver – Analog Closed Loop Control – [Link]
