Inteligent Power Module (IPM) Board for Brushless Motors

Inteligent Power Module (IPM) Board for Brushless Motors

1713
Views
0 Comments

Intelligent Power Module (IPM) board has been designed using FSBS5CH60 IC from Fairchild, which provides a fully-featured, high-performance inverter output stage for AC Induction, BLDC, and PMSM motors. These modules integrate optimized gate drive of the built-in IGBTs to minimize EMI and losses, while also providing multiple on-module protection features including under-voltage lockouts, over-current shutdown, and fault reporting. The built-in, high-speed HVIC requires only a single supply voltage and translates the incoming logic-level gate inputs to the high-voltage, high-current drive signals required to properly drive the module’s internal IGBTs. Separate negative IGBT terminals are connected to shunt resistor to provide the current feedback to the micro-controller. This IPM module helps to develop lots of power applications and also can be used as H-Bridge for brushed DC motor. The module is manly helps to drive Hall sensor based or encoder based motors, it doesn’t support FOC algorithm, FOC based IPM board is under development and will be publish soon.

Inteligent Power Module (IPM) Board for Brushless Motors – [Link]

tags
BLDCFSBS5CH60H-bridgeIGBTMotorPMSM
