SOUNDCAM – The World First True Handheld Sound Camera for Everyone

Every day of our lives we get bombarded with different sounds around.  Loud music, radio, people talking on their phone, automobile, traffic, and those unknown late night quacking sounds. All of these sounds are what makes our day to day activities, and we have even gotten accustomed to most of them and rarely get disturbed by them. However, when an unwanted sound keeps popping into our life, altering our general state of mind and starts becoming a nuisance, we start looking for ways of finding the source of the sound in the hope of getting rid of it. The human ear does an excellent job of finding the source of sounds but can quickly get confused when their many sounds are popping around, or the sounds are slightly dense. Sound localization is a critical concept due to its numerous application and research has been poured into this. The team from CAE system are launching a first of its kind called SOUNDCAM that will allow one to visualize any sound source.

CAE Softwares and Systems, a Germany-based company, is launching SoundCam on KickstarterSOUNDCAM is the first camera that images sound and is affordable for everyone. The system is intuitive and as easy to use as a smartphone. SOUNDCAM locates sound sources in real time and immediately displays the results on the screen. SOUNDCAM visualizes complex acoustic information and creates a connection between hearing and seeing. Analyzing and understanding sound has never been easier! Not only does SoundCam does the job well, but it also comes cheap as compared to traditional acoustic cameras (could cost upwards of $100,000).

SoundCam Handheld Sound Camera

SOUNDCAM localizes every sound source. It is possible to analyze environmental noise, road traffic noise, aircraft noise, train noise, industrial noise, machinery noise, workplace noise, detect malfunctions or leakages, and evaluate vehicle emissions, home appliances, consumer electronics, and a million other noise sources!

The application of SOUNDCAM is endless. I remember sometimes ago; I notice a disturbing noise was coming from my car’s engine side when putting on reverse mode but goes off when on drive or other modes. This was always annoying, and when I took it to my mechanic, he wasn’t sure where the sounds were coming from. After guessing around and dismantling a few parts, still couldn’t find the source of the sound and he suggested to open up the whole engine to see if it was from inside the engine, well, of course, I wasn’t ready to allow anyone open up my whole engine without being sure of what he or she is looking for. I left the car like that until one day it either suddenly disappear or I got used to it that I didn’t observe it again. A perfect application of SOUNDCAM will have been in this scenario, SOUNDCAM will have possibly identified the location of the sound in a non-invasive mode saving hours of lost productivity, money, and precious time. SOUNDCAM can also find applications in buildings for detecting sound leakage in supposed sound-proof structures, in electronics, drones, noise analysis, factories, automobile testing and evaluation, military applications, and thousands of possibilities.

SOUNDCAM consists of 64 microphones, an optical camera, an integrated data acquisition and analysis system, as well as a display and control unit with touchscreen and hardware buttons. The system displays high-resolution results in real time on it’s screen. The algorithm running on SOUNDCAM analyze the time delays it takes for a sound propagated to travel from its source to the microphone array and calculates the accurate acoustic pictures and videos in real time. The optical camera is used to generate the needed optical information, and optical and acoustic pictures are overlayed. These overlayed results are then displayed on the screen.

The SOUNDCAM device is battery powered and waterproof IP54 rated which means there is a possibility it can even be used underwater (of course at your own risk). It is powered by quad-core ARM A53 running at 1.2GHz speed with 1GB of RAM. The display is touchscreen removing the need for keyboard or mouse, but those can still be added through its onboard USB board which is as well used for exporting data from the device. It runs Linux out of the box with an optional Windows support available. It provides support for interfacing with a computer unit through its ethernet port.

SOUNDCAM is launched on Kickstarter with the SOUNDCAM early bird starting at a discounted 3,999 EURO, a 50% from the expected retail price. Shipping is expected to commence in late 2018 to early 2019. SOUNDCAM will revolutionize a lot of work and will save hours of lost productivity in troubleshooting sound localization problems which will inevitably save cost.

Phantom v2640 – The World’s Fastest High Speed Camera Captures 303,460 fps

Vision Research‘s latest addition is the new Phantom v2640 model to its array of products. This is seemingly the world’s fastest video capturing camera, able to record up to 11,750 fps in color and HD or 25,030 fps in monochrome. The maximum resolution is 2,048 x 1,952 pixels with up to 6,600 fps.

Phantom v2640 - the world's fastest video camera
Phantom v2640 – the world’s fastest video camera

At maximum resolution, it can only manage 6,600 images per second but this is enough to provide smooth x100 slow motion replay. HD (1920×1080) mode offers reduced resolution but accomplishes an impressive 11,750 fps. Things can get really breathtaking in monochrome ‘binning mode’ where up to 25,030 fps are possible. Playing the footage at the standard 24 fps gives out at more than a thousand times slow motion.

Apart from scientific applications and materials research, the capabilities of the camera would make it valuable for recording low-frequency sound events in high resolution. One obvious application could be making it a useful tool to study the movement of a bass speaker or subwoofer cone to determine membrane stability and surface resonances. Although it would not be quite fast enough to do the same job for tweeters operating at the upper limits of audibility. There is a special very high-speed mode in the camera which pushes up the frame rate up to 303,460 fps, providing images with a 1792 x 8 pixels format. This would be enough to record tweeter membrane movement but only along a very thin slice of the motion.

This camera is a technical marvel. A pixel rate of up to 26 Gpx/second suggests there are some fairly extreme high-speed electronics, resulting in a data rate reaching way in the GB/s range. As a result, the camera requires a massive internal frame-buffer to record footage of more than just a few milliseconds. Regards this, there is up to 288 GB of RAM installed which is enough to capture at least 7.8 seconds of footage. There is also a fast Ethernet interface of 10 Gb/s and other alternative data transmission connections. Battery operation is available but not necessarily too practical because the camera draws 280 Watts of power. Availability and pricing information is not available yet.

MediaTek Sensio, is a 6-in-1 biosensor module for smartphones

Smartphones in recent times have contributed to the growth of the medical sensing industries with a major success in the usage of a smartphone camera and flash to detect heart rate. Specialized Apps installed on the phone can use the phone inbuilt camera and flash to read an individual heart rate with high accuracy but nothing else in the space of health monitoring. Sensio is a biosensor that will allow smartphones to track six different health metrics, a big game changer in the smartphone and medical industry.

Related image

The Taiwan-based mobile chipset maker MediaTek has recently introduced MediaTek Sensio, the Industry’s first 6-in-1 biosensor that will turn smartphones into a personal health companion. Sensio will come as an embedded module for smartphones which make it possible to easily check and monitor one’s physical wellness.

The MediaTek Sensio MT6381 will allow smartphones to track a user’s heart rate, blood-pressure, heart-rate variability, peripheral capillary oxygen saturation, ECG (Electrocardiography) and photoplethysmography (PPG). It works using an integration of hardware and software in order to measure all these health data in about 60 seconds, as claimed by MediaTek. The company will have an app that can track all of this data and have it accessible to the user and also stored in the cloud.

Related image

The MediaTek Sensio module uses a combination of LEDs (light emitting diodes) and a light-sensitive sensor to measure the variations in red and infrared light from the user’s fingertips. The module is able to measure the ECG and PPG levels by creating a closed loop between the user’s heart and the biosensor which is made possible when the user touches the electrical sensors and electrodes on the device.

The following are the features of the MediaTek Sensio:

  • Heart Rate – Measures heart beats per minute.
  • Heart Rate Variability – Measures variation in the time between heartbeats.
  • Blood Pressure Trends – Measures blood pressure trends to help users see data over a period of time.
  • Peripheral Oxygen Saturation (SpO2) – Measures the amount of oxygen in the blood.
  • Electrocardiography (ECG) – Measures the electrical activity of the heart over a period of time and displays it in graph form.
  • Photoplethysmography (PPG) – Measures the change in volume of blood.

The MediaTek Sensio module includes the following:

  • Integrated R and IR LEDs for reflective PPG measurement + 1 -channel ECG analog front -end.
  • Compact 6.8 mm x 4.93 mm x 1.2 mm OLGA 22-pin package.
  • Total External BOM: 4caps + 2 electrodes
  • I2C / SPI digital interface.

“Giving people the power to access their health information with a smartphone is a major step in making the world a healthier place,” said Dr Yenchi Lee, Sr. Director of Product Marketing for MediaTek’s wireless business. The MediaTek Sensio is expected to be available beginning in early 2018.

L20G20IS Gyroscope: The secret behind the perfect picture

STMelectronics introduces a super tiny two-axis gyroscope (L20G20IS), a Micro-Electro-Mechanical system (MEMS) designed for the optical image stabilization for Smartphones with less energy consumption compared to its predecessor (L2G2IS).

A gyroscope, or gyro for short, adds an additional dimension to the information supplied from the accelerometer by tracking rotation or twist. An accelerometer measures linear acceleration of movement, while a gyro on the other hand measures the angular rotational velocity.

The gyro and the accelerometer work together to detect the rotation of phone and other features like tilting of phone while playing racing games, enhancing the overall gaming experience or in this case, achieving optical image stabilization.

The L20G20IS ultra-compact square gyro uses 25% less surface to shrink camera module size, simplify circuit design and allowing development of thinner devices. The gyro fixes the thin substrates deformations resulted by smartphone moves to ensure consistent measurements for image stabilization.

Features:

  • ±100 dps / ±200 dps full-scale range
  • 5 degree phase delay · 3.8 mdps/√(Hz) rate noise density
  • Wide supply voltage range: 1.7 V to 3.6 V
  • Low-voltage compatible IOs
  • 3- and 4-wire SPI digital interface
  • Embedded temperature sensor
  • Embedded self-test
  • Integrated low-pass filters with user-selectable bandwidth
  • Power-down and sleep modes for smart power saving
  • ECOPACK®, RoHS and “Green” compliant
  • Volume (2.0 x 2.0 x 0.7)mm
  • Zero-rate Level: 0.03dps/°C (range: -20°C to 75°C)

Also L20G20IS includes a sensing element and an IC interface capable of providing the measured angular rate to the application through an SPI digital interface. It is compatible with single- or dual-camera modules and is available now in the 12-lead 2mm x 2mm LGA package.

Zero-rate level: This value indicates “the deviation of an actual output signal from the ideal output signal if no acceleration is present”, or more clearly the output value that will be generated when there is no movement on the device. This is very important for the phone, it needs to know when it is not moving to be able to stabilize the images with the appropriate values.

Results

Smaller but more efficient gyroscope! The L20G20IS boots 30% faster (in less than 70ms) consuming just 1.4mA (50% less of current than usually). Although, the temperature can affect the sensitivity and the zero-rate level of the gyro, producing wrong measurements for image stabilization by the phone. However, the L20G20IS device has a integrated temperature sensor to guarantee sharper images to the users even with long exposure times.

The smart-camera software saves even more battery with the power-down and sleep modes. Another improve is the  suppression ratio of 6dB, it gives outstanding optical correction to banish camera shake from smartphone photography.

Source:  Micro-Electro-Mechanical Systems (MEMS). ST is a world leader in MEMS devices for mobile applications, with more than 900 MEMS-related patents and patent applications worldwide.

Apertus AXIOM Professional Digital Cinema Camera is open source

Apertus AXIOM Beta is a professional digital cinema camera built around free open source software and hardware. AXIOM Beta is the latest version powered by MicroZed development board based on Xilinx Zynq 7020 ARM + FPGA SoC, and running Arch Linux ARM. The camera will run Arch Linux ARM on MicroZed board, support common network protocols (SSH/FTP/SCP/etc), and be configurable via a web interface. It has many interesting specification as listed below, however audio recording is not currently supported. Many more software and hardware details can be found in their Wiki.

AXIOM Beta developer kit hardware specifications:

  • “Linux” Board – Xilinx Zynq 7020 based MicroZed board
  • Beta Main Board – Hosts two external medium-speed shield connectors and two high-speed plugin module slot connectors.
  • Image Sensor – 12MP CMV12000 (Used for research and development) via CMV12K ZIF Sensor Board
  • Lens Mount Passive E-mount
  • Ports – USB / USB UART / JTAG / Gigabit Ethernet
  • Modules and Shields
    • Single HDMI Full HD (4:4:4) output at up to 60 FPS
    • Dual 6G SDI output (in development)
    • 3x PMOD debug module
    • LED matrix debug module
    • Genlock, Trigger, Timecode, LANC shields (in development)
    • 4K Displayport/HDMI (in development)
  • Power Supply – 5V/5A via power adapter board; Other voltages provided via Beta Power Board
  • Dimensions -111.76 x 74 x 65.1 mm (devkit)
  • Weight – 319 grams (devkit)

A Compact Camera Using Raspberry Pi A+ And Adafruit TFT Display

PiJuice at instructables.com designed an interesting compact camera project with raspberry pi. Raspberry Pi A+ is used in this project as it is the cheapest and smallest available Raspberry Pi. The real challenge in this kind of portable Pi projects is powering the Raspberry Pi. This issue is solved using PiJuice—an all in one battery module for the Raspberry Pi.

Required Parts

Required parts to make Raspberry Pi compact camera
Required parts to make Raspberry Pi compact camera

Set Up The Raspberry Pi

Download the latest version of the Raspbian image from the Raspberry Pi Website and burn it on your blank SD card. You can use win32DiskImager or your favorite software to get the job done. Now, you need to install the drivers for the TFT screen by running the DIY installer script, explained on the Adafruit page. Connect the TFT to the Raspberry Pi, attach the PiJuice with a charged battery, and switch it on. Your screen now should display boot up messages.

Connect The Camera

Insert the ribbon cable of your camera module properly ensuring that the blue side of the ribbon is facing away from the HDMI port. Now, go to the terminal and type the following command,

sudo raspi-config

Enable the camera in the menu and then reboot the Pi. The camera should work properly after a successful reboot. To test the camera, enter the following command:

raspistill -o pic.jpg

This will take a snap and save it in the /home/pi directory.

Connect A Push Button

You need a push button to simulate a shutter action. Locate the pin 17 on the GPIO breakout on the top of the TFT screen. Now, solder two wires to the terminals of the push button. You can either solder a right angle header to the pin 17 or you can directly solder one wire from push button to that pin. There is a pad labeled WP on the board. It is actually connected to the ground. Solder another wire from the push button to this pad.

Install And Test The PiCam Software

To install the software, the Raspberry Pi must be connected to the internet. Enter the commands given below to download and install PiCam.

sudo apt-get install git-core
sudo mkdir PiCam
cd /PiCam
git clone git://github.com/pijuice/PiCam.git

Once the software has been downloaded, navigate to the PiCam directory using the command:

cd /picam

You can run it by typing the command:

sudo python picam.py

Now, you can take pictures by simply pressing the push button. Once the button is pressed the picture will be taken. Once the captured image gets loaded, your photograph will be displayed.

Taking photograph with Raspberry Pi compact camera
Taking photograph with Raspberry Pi compact camera

Conclusion

Your Raspberry Pi camera is ready now. If you want to make it even more compact as well as portable, grab the official laser-cut compact camera case from the Kickstarter page by pre-ordering a Maker Kit. You can also build your own simple chassis for housing the camera.

Pi Desktop Case – include peripherals too

The ‘Pi Desktop’ kit from element14 offers some great features like Wi-Fi, Bluetooth, a real-time clock, an interface for an mSATA-SSD hard drive, an optional camera, heat sink, a neat power switch and of course the sleek black case. [via]

The Raspberry Pi is a well designed, powerful and inexpensive board, but not a complete computer. Some distributors know you need more than just a plastic case and a mains-adapter power supply (or USB cable). The ‘Pi Desktop’ kit from element14 contains everything you need and more, turning your RPi into a fully fledged computer.

Pi Desktop Case – include peripherals too – [Link]

Fast Single-Pixel Camera

Compressed sensing is an new computational technique to extract large amounts of information from a signal. Researchers from Rice University, for example, have built a camera that can generate 2D-images using only a single light sensor (‘pixel’) instead of the millions of pixels in the sensor of a conventional camera.

This compressed sensing technology is rather inefficient for forming images: such a single-pixel camera needs to take thousands of pictures to produce a single, reasonably sharp image. Researchers from the MIT Media Lab however, have developed a new technique that makes image acquisition using compressed sensing fifty times more efficient. In the example of the single-pixel camera that means that the number of exposures can be reduces to several tens.

One intriguing aspect of compressed sensing is that no lens is required – again in contrast with a conventional camera. That makes this technique also particularly interesting for applications at wavelengths outside of the visible spectrum.

In compressed sensing, use is made of the time differences between the reflected light waves from the object to be imaged. In addition, the light that strikes the sensor has a pattern – as if it passed through a checkerboard with irregular positioned transparent and opaque fields. This could be obtained with a filter or using a micro-mirror array where some mirrors are directed towards the sensor and others are not.

The sensor each time measures only the cumulative intensity of the incoming light. But when this measurement is repeated often enough, each time with a different pattern, then the software can derive the intensity of the light that is reflected from different points of the subject.

Source: Elektor

Raspberry Pi Security System

MWAGNER @ hackmypi.com build a security camera based on Raspberry Pi:

A family member asked me to put a camera in our garage recently, and immediately I decided to use a Pi Zero. Back when I was interviewing for my current job, I was dabbling with the idea of making a wireless, battery powered IP camera that I was going to attach to my dog, and get some cool footage of my dog running around.

Raspberry Pi Security System – [Link]

Building A Tiny Portable Time-lapse Camera

Using a mini spy camera module, Ruiz Brothers had built a tiny portable camera that is used to take time-lapse videos and for all sorts of photo based projects.

This project consists of these parts with an estimated cost of $39:

The mini spy camera module has an integrated driver and is easy to use without an Arduino or Raspberry Pi. The camera sensor can take 1280×960 photos and captures video at 480p. The module uses a microSD card to store data and it has a maximum support of 32GB. For a higher image quality and adjustable settings, you can use other camera modules such as the Wearable Raspberry Pi Zero Camera.

To take a time-lapse, an intervalometer remote control is needed to trigger the camera for capturing a photo within a constant interval. The Adafruit Trinket microcontroller is used here, and you can also make your own following this guide.

The circuit will be powered by a 3.7V 100mAh Lithium Ion battery via JST connection. The battery plugs directly into the Trinket Backpack, which allows the recharging over the microUSB port on the Trinket.

The circuit is connected as shown in the diagram; the slide switch to Lipoly backpack, VCC from camera to 5V on Trinket, GND from camera to GND on Trinket, BAT from Lipo backpack to BAT on Trinket, G from Lipo backpack to GND on Trinket, and 5V from Lipo backpack to USB.

The code is very simple and can be uploaded to the controller using the Arduino IDE. The setup loop will initialize the pins, and the loop will turn on and off the trigger with a chosen delay.

int trig = 0;
int led = 1;

void setup() {
  // initialize the digital pins as output.
  pinMode(led, OUTPUT);
  pinMode(trig, OUTPUT);

  digitalWrite(led, HIGH);
  digitalWrite(trig, HIGH);
}

// Hold HIGH and trigger quick (<250ms) LOW to take a photo. Holding LOW and trigger HIGH starts/stops video recording

void loop() {
  digitalWrite(trig, LOW);
  digitalWrite(led, HIGH);

  delay(50);

  digitalWrite(trig, HIGH);
  digitalWrite(led, LOW);

  delay(5000);
}

The case in 3d printed, the design with a detailed description and the full making guide is available here. This video is showing how to make this tiny camera and how it works.
