Make Your Own Arduino Nano In The Simplest Way (DIY – Arduino Nano)

In today’s post, we are going to learn how to make an Arduino nano at home. Electronics enthusiast Pratik Makwana designed this project in instructables.com. Every step in this project is well-explained. If you already don’t know what Arduino Nano is then here is a brief introduction: Arduino Nano is a tiny yet strong member of the Arduino family. It’s powered by an ATMega328P microcontroller running on 16MHz. But, the main strength is its very small form factor.

Arduino Nnao
Arduino Nano

Now, let’s get started and make your own Arduino Nano in no time.

Requirements:

  • Copper clad board (Double-sided)
  • Ferric Chloride (FeCl3)
  • Acetone (Nail polish remover)
  • Glossy Paper
  • LASER Printer
  • Marker Pen
  • Scissors
  • Plastic container
  • Sandpaper
  • Safety gloves (Optional)
  • Latex gloves
  • Saw – For copper board cutting
  • Laminator or iron
  • Components of Arduino Nano (Given later)

PCB Designing:

This is a very important step of this tutorial. You need to draw the circuit of Arduino Nano first. Then you’ll design the PCB using the schematic. Design the schematic diagram in an EDA tool (Electronic design automation Software).
Here is a list of EDA Tools:

EAGLE is the most widely used PCB and schematic design software. Though my personal favorite is Proteus. You can use any software from the list.

Importing the Schematic File to PCB Editor
Importing the Schematic File to PCB Editor

To make the schematic, use the Arduino Nano Circuit Diagram and Arduino Nano Components List. Once it’s drawn completely, open the PCB designing part of the software and you’ll see that schematic is imported there. Now place the components in correct places and connect them using traces. If you are using EAGLE then you can simply download the Arduino Nano Schematic File for EAGLE and Arduino Nano PCB File for EAGLE. Open the .brd file (PCB file) to print the PCB. You can also modify it if you wish.

Place the parts in correct position
Place the parts in correct position
Connect the components and the PCB is ready
Connect the components and the PCB is ready

Note:

  • Use Only Laser printer only.
  • Use glossy papers to print.
  • Set scale factor to 1.
  • Before top layer printing, you need to mirror the image of the top layer layout.

Cut The Copper Clad Board:

Now, cut the copper clad board according to the dimensions of the PCB. You can use a hacksaw to cut it off. Be precise about the dimensions. If it’s smaller than the actual PCB then you have to do it again. Also, cut the printed glossy paper as per the size of PCB.

Cut the copper clad board using a hacksaw
Cut the copper clad board using a hacksaw

Toner Transfer and Etching Process:

In this step, the PCB design from glossy paper will be transferred to the copper board. All you need to do is place the printed side of the glossy paper on the copper board and apply both pressure and heat. You can use a modified laminator machine or an iron for this purpose. Why “modified”? Because toner transfer method requires a temperature of 210°C, where a laminator can provide 150°C maximum.

Put the board in FeCl3 solution for a while
Put the board in FeCl3 solution for a while

Make your copper clad board as clean as possible beforehand. You can use sandpaper and alcohol to do this. When the toner is transferred successfully, prepare the ferric chloride (FeCl3) solution. Before putting the board into the solution check carefully for any broken path. If found, draw it with a marker. After the etching process, use the acetone to clean the board.

After washing the PCB with Acetone
After washing the PCB with Acetone

Drilling & Soldering:

Drill the PCB using PCB drill machine. Choose the drill bit wisely else components may not fit. Now, place the components on the PCB and solder them. You can use a helping hand device to get it done nicely.

Upper layer of PCB
Upper layer of PCB
Lower layer of PCB
Lower layer of PCB

Burning The Arduino Bootloader:

In this step, you’ll need another Arduino board (e.g. Arduino UNO) to burn the bootloader to your newly made Arduino Nano for the first time. Open Arduino IDE and upload the ArduinoISP sketch to the Arduino UNO from examples option. Now, connect your Arduino Nano with Arduino UNO over SPI bus following the given instructions:

  • Arduino UNO     >>    Arduino Nano
  • ——————————————-
  • SS (Pin 10)         >>     RESET (Pin 29)
  • MISO (Pin 11)    >>     MISO (Pin 16)
  • MOSI (Pin 12)    >>    MOSI (Pin 15)
  • SCK (Pin 13)       >>    SCK (Pin 17)
  • 5V                         >>    VCC
  • GND                    >>    GND
Follow this instruction to burn bootloader
Follow this instruction to burn bootloader

After making the connections, go to Arduino IDE and follow the given instructions:

  1. Select Tool  >>  Board  >>  Arduino Nano
  2. Select Tool  >>  Port  >>  Select your Arduino UNO COM Port
  3. Select Tool  >>  Programmer  >>  Arduino as ISP
  4. Select Tool  >>  Burn Bootloader

Wait for the “Done burning bootloader” message to appear.

Testing:

Well, your Arduino Nano is now ready for a test run. This time you won’t need another Arduino to upload codes. Follow the instructions and connect a USB to TTL converter (a.k.a USB to UART converter) with the Arduino nano to upload sketches.

  • USB to TTL Converter (CP2102)  >>  Arduino Nano
  • —————————————————————-
  • VCC        >>     VCC
  • TX          >>    RX (Pin 30)
  • RX         >>    TX (Pin 31)
  • DTR      >>    RESET (Pin 29)
  • GND     >>    GND
  1. After making the connections, go to Arduino IDE and perform the following tasks:
  2. Select File  >>  Examples  >>  01.Basics  >>  Blink
  3. Select Tool  >>  Board  >>  Arduino Nano
  4. Select Tool  >>  Port  >>  Select your Arduino UNO COM Port
  5. Select Tool  >>  Programmer  >>  AVRISP MKII

After that, upload Blink Sketch to Arduino Nano and wait for the “Done Uploading” message. LED connected to pin 13 should blink if everything is OK. Now you can upload any sketch you wish to your home made Arduino Nano.

Conclusion:

So, this is how you can make your Arduino Nano. All you need for this project is PCB designing skill and a pretty good soldering skill as you have to deal with SMD components. This way you can make custom Arduino Nano that will fit your project perfectly. Watch the video to have a more clear idea:

RELATED POSTS

DIY Arduino-Based Desktop CNC Router

Inspired by machines like the Nomad 883 from Carbide3D, Carvey from Inventables and more, Thimo Voorwinden had come up with a new tutorial for building a desktop CNC router powered by Arduino.

This CNC budget is around €200 and you don’t need a workshop to build it up, basic tools will do. It is designed to be modular, Arduino powered, and with a tolerance of (±0,1 mm). It has Ø8 mm linear rods, M8 thread lead screw and uses NEMA 17 stepper motors and drv8825 drivers. Plus, 250 watt flexible shaft is needed to drive the spindle and it has a work area of 200 x 250 x 100 mm (x,y,z).

Here you are the Bill of Materials that Thimo made based on his research in German and Chinese web-shops:

The tools Thimo used to build this CNC are listed here:

  • Homemade router table
  • Old ‘cordless’ drill
  • Ø22 mm wood spade drill
  • A rusty collection of old metal drill bits
  • Hammer
  • Metal saw
  • File
  • Screw drivers
  • Clamps
  • Try square
  • A soldering iron

Thimo shared this experience as a 5 HD video tutorials on Youtube to explain all the steps he went through: setting X and Y axis, the frame, Z axis and spindle, electronics and a video where the CNC is in action while milling a jigsaw piece. He added two extra videos for foam milling and testing the plotting function. Check them out here:

“For about €200 I’m now capable to CNC machine wooden parts. Not at a high speed, or without any bumps along the way, but having this option is still great. I will definitely try to machine some gears, specific parts for projects and engrave signs with this in the future.”

For more information, a detailed guide, and some notes check the project’s page at Thimo website.

Open Source DIY Laptop Kit By Olimex

Olimex Ltd is a Bulgarian leading provider for development tools and programmers for embedded market. The company has 25+ years’ experience in designing, prototyping and manufacturing printed circuit boards, sub-assemblies, and complete electronic products.

The latest amazing product by Olimex is an open source laptop DIY kit called: TERES I.
TERES I is open source hardware and software Do It Yourself laptop running Linux on 64- bit ARM processor. It’s very light less 1 kg and convenient to carry with when travel. The core of this laptop is built around an Allwinner ARM Cortex-A53, 1GB of DDR3L RAM, 4GB of eMMC Flash, WiFi, Bluetooth, a camera, and an 11.6″ 1366×768 display.

Back to history, Teres I was the first king of the Odrysian state of Thrace where Plovdiv – the city where TERES I laptop was designed. The Odrysian state was the first Thracian kingdom that acquired power in the region, by the unification of more than 40 Thracian tribes under a single ruler!

The stylish and elegant shape laptop is open source hardware and software, so people can learn and study how it’s done. The CAD files and source code is on GitHub and everybody can download and modify and use for their own need.

“If you want to implement new features nothing stops you. If you need another processor, more power, more memory, better LCD, you are free to do this and tailor this laptop to your needs! If you do not like the Linux distribution you have access to the sources and can generate any Linux distribution to your taste!”

The laptop is modular which means that there is number of possibilities to expand it for example by adding a FPGA expansion module in order to give the laptop some extra capabilities like Digital Storage Oscilloscope, Logic Analyzer and much more features. This expansion module and others are under construction now and will be launched soon.

You can also order any spare part of the laptop since all it’s components available for purchase, which makes maintenance easier and cheaper.

TERES I DIY kit is available for €225 in two colors white and black, and it contains the following parts:



  1. PCB1 A64
  2. PCB2 IO
  3. PCB3 TOUCH
  4. PCB4 BTN
  5. PCB5 KEYBOARD
  6. LiPo 7000mAh
  7. Bottom
  8. Keyboard
  9. LCD Frame
  10. LCD Back
  11. Power Button
  12. Touch Buttons
  13. Speaker Left
  14. Speaker Right
  15. LED pipe
  16. Screws Set
  17. Hinge Set
  18. Mats Set
  19. Magnet
  20. Camera
  21. Camera Lens
  22. Dust Protectors
  23. Touch Cover
  24. Touch
  25. WiFi Antenna
  26. LCD cable
  27. FPC IO Main
  28. FPC Power Main
  29. FPC Touch Button
  30. FPC Kbd Button
  31. Power Adapter
  32. Microphone



This laptop could be the next educational gadget for your kids or students. You can use it to explain for them in action how computers work and what do they consist of. It will give them the chance to think deeper in the fields of electronics and programming while assembling the laptop for the  first time and if any trouble occurred  and they have to help in solving it. This educational benefits of TERES I could not be available unless the laptop is completely open source.

It is true that the specifications of this laptop may not be perfect, but no one can deny that the price tag is cool making this laptop a consumable choice for some usages. This DIY kit is out of stock now as mentioned on the website, but you can register your email on the product page to be notified once it is available.

TERES I is completely designed with KiCAD FOSS, also hardware and software source files are available on Github. Also check this file to know more details about the laptop and the building instructions.

A few months ago, Tsvetan Usunov the brain behind Olimex had conducted a talk at Hackaday Belgrade conference about his upcoming DIY laptop kit. Check it out!

EEZ H24005, Two-Channel Programmable Power Supply

Envox Experimental Zone (EEZ) is an open hardware and open source development website, that creates and shares various open source hardware and software projects using as much as possible open-source tools and technologies.

One of their projects is the programmable bench power supply ‘EEZ H24005’. The goal is to make a reliable, modular, open and programmable power supply, that can be used for various tasks starting with powering breadboard, charge batteries of various types, or to be used as an educational tool and science experiments.

The EEZ H24005 is a DIY power supply unit consists of four PCBs and SMT electronics components except some power resistor, AC/DC adapter, and power regulators. Only two ICs need hot air soldering station to mount, while the remaining parts can be simply mounted with soldering iron.

Top Faces Of The Four PCBs
Bottom Faces Of The Four PCBs

To build this PSU you will need these tools:

In addition to modularity, programmability, openness, and DIY, reliability was one of the key features and design guidelines of the designing process. Because as a sourcing device, the PSU has to be designed in the way that no dangerous oscillation in voltage or current is present over the long period of deployment. That includes border case of turning the PSU on and off, applying or disconnecting load, etc.

Here is some of the main features of H24005:

  • Modular design that allows combining modules with various performance and capability and creation of multiple output solution
  • Voltage regulation (CV), 10 mV resolution
  • Current regulation (CC), 10 mA initial resolution
  • Various current single range operation (0-5 A default, 0-3 A or 0-4 A per channel)
  • 15-bit data acquisition resolution
  • Real-time clock (RTC) with supercap/battery backup
  • SD-card as an additional storage
  • Ethernet support for remote control
  • Simple DC output protection (reverse voltage, over-voltage)
H24005 PSU Block Diagram

Since it is an open source project, all files, designs, source codes are available at the Github repository. Also a detailed building guide is available at the official website. But if you want to get H24005 but not interested in making it, you can order yours through OSHPark. There is also a CrowdSupply campagin on going.

“DIY LiFePO4 Charger” Challenge by Elektor

A new challenge is posted on Elektor, for building a charger project for 3.6-V single-cell lithium iron phosphate (LiFePO4), a kind of Li-Ion rechargeable battery for high power applications, such as EV car , Power Tool and RC hobby. Elektor magazine has so many DIY projects about battery chargers and none of them is about this battery, so it thinks now the time to make everyone contributes by sharing their inventions. Below sharing some information in order to complete the challenge.

Intersil’s ISL78693 is qualified to AEC-Q100 Grade-3, leaks only 3 µA, and is suitable for eCall back-up battery charging. In the event of a crash, eCall systems are intended to automatically broadcast location and contact the nearest 24-hour emergency call centre for help. They must “be capable of operating reliably and autonomously from the backup battery at a moment’s notice, even if the vehicle is involved in an accident minutes after being parked for several months,” said Intersil. 3 µA is a maximum, with typical leakage of 700 nA.

LiFePO4 chemistry needs charging at 3.6 V – less than the 4.2 V typically offed by charge chips aimed at more conventional Li-ion cells. Charging is up to 1 amp. A charge current thermal fold-back feature prevents over-heating by automatically reducing the battery charging current, and low-temperature detection prevents charging if the cell is too cold to accept electrons.

The ISL78693 requires only five external passive components. It’s a linear charger, so none of these are inductors. More good news: the 3.6-V ISL78693 is pin-compatible with the 4.1-V ISL78692 Li-ion battery charger. Neither will work from nominal 12-V car voltages though so you have to slap up some dc-dc converter to bridge the gap.

No articles had been launched yet about making the charger, you can be the first! It is true that no awards are mentioned, but at least you will make the world a better place by sharing your ideas. Go to www.elektormagazine.com/labs, share your LiFePO4 project and be a part of this DIY power supplies challenge by Elektor.

Source: Elektor

DIY Breathalyzer Using Arduino UNO

Today I am going to discuss how to make a very simple DIY Breathalyzer using Arduino UNO and few external components. Ana Carolina designed this project as an instructable in instructables.com. This is a low-cost project and a useful one too. If you have no idea about what breathalyzer is, let me explain briefly: A breathalyzer is a device for estimating blood alcohol content (BAC) from a breath sample. Check the link given for more information.

Arduino Based Breathalyzer
Arduino Based Breathalyzer

Requirements:

  • Arduino Uno
  • MQ-3 Alcohol Sensor
  • 128×64 LCD (Liquid Crystal Display)
  • 7 × 330 Ohm Resistor
  • 7 × LEDs (1 Red, 2 Yellow, 3 Green and one other color)
  • Jumpers Wires
  • Breadboard
  • Soldering Iron (optional)
  • Solder Wire (optional)

Details:

This project is very simple. Here we are using an array of six LEDs and a 128×64 LCD to display the alcohol level. The presence of alcohol is sensed by an MQ-3 alcohol sensor and then analyzed by an Arduino board. We are using Arduino UNO in this project, but any model can do the job.

Three Green LEDs represent that alcohol level is OK and within the safe limit. Two Yellow LEDs are used to describe that safe limit is going to be reached, and you know it well why the Red LED is there. In fact, those LEDs are used just to give you a quick idea. If you want to know the exact value, the display is there for you.

You can tweak the program and re-calibrate the breathalyzer. But you must remember that breathalyzer doesn’t precisely measure your blood alcohol content, rather it estimates a value from the amount of alcohol in your breath.

Circuit:

Breathalyzer Circuit On Breadboard
Breathalyzer Circuit On Breadboard

You can make the circuit also on PCB or Veroboard. But for the prototyping purpose, the breadboard is the best choice. You can see how straight forward the connections are.

The Code:

Some part of the original code was in Portuguese. So I have translated it into English. Also, the original code shared by the author in instrucatbles.com is a buggy one. So, I recommend you to use my bug-free code instead of the original one.

Please note that you have to download and add the u8glib library in Arduino IDE beforehand. It is very important. You can either download the u8glib v1.14 library for Arduino directly or go to the site and choose what to download.

Follow the given steps to add a .zip library in your sketch: Open IDE and click on Sketch  Include Library  Add .zip Library. Now select the downloaded .zip library file. You needn’t unzip it.

When everything is done, verify and upload the code to Arduino.

Test It:

I must not recommend you to drink alcohol just for testing the breathalyzer. Rather get a towel and spray alcohol on it. Now hold the towel in front of the sensor. Move it back and forth to observe the change in reading. It may take a while for the breathalyzer to stabilize.

Consider watching the video for a better understanding:

RELATED POSTS

DIY Home Energy Meter

A new tutorial by The DIY Life is for building a home energy meter that provides information about power consumption and cost estimates for the month.

Using Arduino and some other components you can build your own energy meter that measure the supply current to your home through a CT (current transformer), current, power, maximum power and kilowatt hours consumed. The cost of electricity used to date can be added and displayed easily.

arduino-energy-meter-high-consumption

Electronics you need to build this project:

  • Arduino Uno
  • LCD Shield / LCD Screen
  • CT – Talema AC1030
  • 56Ω Burden Resistor
  • 10µF Capacitor
  • 2 x 100K Divider Resistors

If you are not familiar with Arduino or LCDs you can check these articles by The DIY Life to learn more: getting started with Arduino, connect an LCD screen

First you have to build the current sensor by connecting the CT to the Arduino and setting a right voltage reference due to the Arduino 0-5V input range. As shown below, this is the way you should connect the CT to the Arduino.

energy-meter-wiring-diagram

This code should be uploaded to your Arduino to run the project. It already has a scaling factor that can be adjusted due to the components you choose in your circuit.If you don’t want to use or don’t have an LCD screen, you can also modify the sketch to output to the Arduino IDE’s serial window as described in this code.

For more information on how to choose different components, how to calibrate them, and to learn more details about wiring and coding, you should check this tutorial out.

The first number displayed is the instantaneous current followed by the instantaneous power. On the bottom line, the kilowatt hours used since reset and then the maximum recorded power since reset. Check the meter in action:

Turn Your Raspberry Pi Into A Wi-Fi Drone Disabler

Note: The information presented here is for educational purposes. This tutorial is designed to help users understand the security implications of using unprotected wireless communications by exploring its use in a popular drone model: the Parrot AR.Drone 2.0. It’s illegal to access computer systems that you don’t own or to damage other people’s property, the techniques should only be performed on devices that you own or have permission to operate on.

Using a Raspberry Pi with a touchscreen, and running a couple of simple Bash scripts, Brent Chapman built a device that will drop Wi-Fi controlled drones right out of the sky with just a tap of your finger.

wifijammer

The device concept is finding the unsecured Wi-Fi access point used by the pilot smartphone or tablet to control the drone, then log on to the drone’s default gateway address, and shuts down the system from the inside without the pilot knowing.

This will only work on some models of drones which use Wi-Fi as the interface between the controller and the drone, such as Parrot’s Bebop and AR.Drone 2.0, that are entirely controlled via Wi-Fi.

The AR.Drone 2.0 is an ideal platform for experimentation and learning thanks to its many impressive features and sensors plus its low cost. It creates an access point named “ardrone2_” followed by a random number, that the user can connect to via a smartphone. This access point is open by default with no authentication or encryption. Once a user connects the device to the access point, he or she can launch the app to begin control of the drone.

raspberry_pi_2298-15

At first, you have to connect the Raspberry Pi with a touchscreen, this guide by adafruit might be helpful. When they are ready, the next step is preparing couple of bash scripts. The first is named “join_network.sh”, and it used to make the Pi automatically join the AR.Drone 2.0 access point.


The second script is named “poweroff.sh”,it will initiate a telnet connection to the drone, then send the command of poweroff, which tells the drone to shut everything down.


The last step is building a “Cantenna”, a DIY directional antenna made of a can to boost the wireless signal. You just need to drill a hole on an empty can to hold a N connector then connect it to Wi-Fi card.

cantenna6

Keep in mind, you should only try this tool on your own personal drones safely and at your own risk. You can find the complete guide at this link at makezine.

Build Your Own I2C Sensor

Since Raspberry Pi doesn’t have a built-in ADC (Analog to Digital converter) to read the voltage off from most of sensors, the best solution is to add I2C ADC chips and modules to your project.

Paweł Spychalski faced this problem while building his own weather station that is based on Raspberry Pi. It collects various data and displays them on dedicated web page and Android app. Every few months he tries to add a new sensor to it. Last time it was a daylight sensor. He added this sensor to his system by using ATtiny85 and it was connected via I2C bus.

ATtiny85 is a member of Atmel tinyAVR series which has 8-bit core and fewer features, fewer I/O pins, and less memory than other AVR series.

The Inter-integrated Circuit (I2C) Protocol is a protocol intended to allow multiple “slave” digital integrated circuits (“chips”) to communicate with one or more “master” chips. Like the Serial Peripheral Interface (SPI), it is only intended for short distance communications within a single device. Like Asynchronous Serial Interfaces (such as RS-232 or UARTs), it only requires two signal wires to exchange information.

I2C uses only two bidirectional open-drain lines, Serial Data Line (SDA) and Serial Clock Line (SCL), pulled up with resistors. Typical voltages used are +5 V or +3.3 V although systems with other voltages are permitted.

425px-i2c-svg
Sample Inter-Integrated Circuit (I²C) schematic with one master (a microcontroller) and three slave nodes

Most of developers use I2C to connect to sensors with the help of the Arduino “Wire” library or “i2c-tools” on the Pi, but it is rare to see someone that is actually building the I2C slave device. Paweł’s project uses TinyWireS library, a slave-mode SPI and I2C library for AVR ATtiny Arduino projects.

This diagram shows how to build analog to digital converter using ATtiny85 and connect it to any device (Raspberry Pi, Arduino) using I2C bus. Here photoresistor has been used, but any analog meter will be fine: temperature, potentiometer, moisture…

ATtiny85 directly connected to Raspberry Pi via I2C, photoresistor with 10kOhm pull down connected to ATtiny85 and signal LED.

attiny_photoresistor_i2c
ATtiny85 directly connected to Raspberry Pi via I2C, photoresistor with 10kOhm pull down connected to ATtiny85 and signal LED.

For reading data you can use this code. ATtiny sends current measurement as two 8 bit value. First older bits, then younger 8 bits.

Wire.requestFrom(0x13, 2);    // request 2 bytes from slave device #0x13

int i =0;
unsigned int readout = 0;

while (Wire.available()) { // slave may send less than requested
 byte c = Wire.read(); // receive a byte as character

 if (i == 0) {
  readout = c;
 } else {
  readout = readout << 8;
  readout = readout + c;
 }

 i++;
}

Serial.print(readout);

To do this project you need to use Arduino IDE 1.6.6., TinyWireS library,ATtiny45/85 board, plus an 1MHz internal oscillator.

Watchdog timer interrupts ATtiny every few minutes, measures voltage, filters it and stores in memory. Every time read operation is requested, last filtered ADC value (10 bits as 2 bytes). I2C support is provided by TinyWireS library that configures ATtiny USI (Universal Serial Interface) as I2C slave.

/**
* This function is executed when there is a request to read sensor
* To get data, 2 reads of 8 bits are required
* First requests send 8 older bits of 16bit unsigned int
* Second request send 8 lower bytes
* Measurement is executed when request for first batch of data is requested
*/
void requestEvent() {
 TinyWireS.send(i2c_regs[reg_position]);

 reg_position++;
 if (reg_position >= reg_size) {
  reg_position = 0;
 }
}

/*
* Setup I2C
*/
TinyWireS.begin(I2C_SLAVE_ADDRESS);
TinyWireS.onRequest(requestEvent); //Set I2C read event handler



Bright by day, dark by night
Bright by day, dark by night

This cool weather station and its need of daylight sensor is only an example. The amazing thing is that you can now build new I2C sensors and introduce new modules to your projects easily following Paweł’s steps.

For more details about this project you can check Github and the weather station website.

A Multi-Use Mini Sensor Platform

While developing a smart hardware project, such as control and automation systems, you will almost need to use different types of sensors for collecting and gathering necessary data. LastSamurai had designed a platform that aims to simplify the use of digital and analogue sensors.

img003The platform was developed based on MySensors Hardware, hardware components that ease up building of the DIY sensors. It tries to solve some issues that other platforms still have like housing. The developer wants to make it smaller than 5x5cm with SMD parts so it can fit in a small case along with a sensor and a battery.

This multi-sensor platform can be powered by a CR2032 battery, external batteries, or an external power brick. Its PCB contains these components:

  • Atmega328P, a high-performance Atmel 8-bit AVR microcontroller combines 32KB ISP flash memory, 1024B EEPROM, 2KB SRAM, and operates between 1.8-5.5 volts.
  • NRF24L01+, an ultra low power RF transceiver IC for 2.4GHz band and 2 Mbps data rate.
  • ATSHA204A, a crypto full turnkey security device with 4.5Kb EEPROM protected hardware-based key storage.
  • AMS1117,  an adjustable and fixed voltage regulator to reach the desired voltage level.
  • SDA/SCL pins for I2C sensors like the HTU21D and Si7021.
  • D2/D3 pins of the atmega which are the digital pins that controller the interrupts 0 and 1.
  • A1 and A2 to be able to connect analog sensors like a plant/soil humidity sensor.
  • Serial connection pins for debugging.
  • 6 pin ISP connection for programming.
OH Mini-Multi-use Sensor Platform
OH Mini-Multi-use Sensor Platform

The platform can be programed using Arduino pro mini settings, and can run either on 3.3V or 1.8V and 8MHz.

It is an open source project, so everyone can contribute on enhancing it  and adding more features. Anyone interested can build it himself by having access to all hardware and software resources at the project page and github repository.
