ECG Arduino Shield

FIPX3OLIMRYIOBF.LARGE

This project is an Arduino shield able to measure ECG and respiration. The shield is equipped with a LCD display to show measured signal in real time. It’s based on ADS1292R ECG Front End from TI.

Recently i made shield for arduino which can measure ECG, respiration, eventually after some changes in PCB and code, EEG and EMG. Big advantage of this shield is possibility to make it easily at home. The shield is equipped by display to show you measured signal real-time.

ECG Arduino Shield – [Link]

OpenHardwareExG: An open source platform for ECG, EEG, EMG, ENG, and EOG signal processing

OpenHardwareExG

OpenHardwareExG, An open source platform for ECG, EEG, EMG, ENG, and EOG signal processing:

The OpenHardwareExG is a platform for ECG, EEG, EMG, ENG, EOG, and evoked potential applications.

The OpenHardwareExG platform was originally developed as part of the eeg-mouse project.

Project goals
The main goal of the project is to build a device that allows the creation of electrophysiologic signal processing applications. In addition:
Hardware and software that we develop will have a free/open source license. We also prefer to use hardware and software that are free/open source.
We would like to keep the hardware DIY compatible (hand solderable, with parts that are readily available in small quantities, etc.)
For us, this is a hobby and learning project. It’s important to keep it fun, and take the time to learn along the way.

[via]

OpenHardwareExG: An open source platform for ECG, EEG, EMG, ENG, and EOG signal processing – [Link]

BITalino – Create projects with physiological sensors

Printoo’s flexible modules provide the ideal form factor to quickly create first product concepts for smart wearables devices. BITalino (http://www.bitalino.com/) is revolutionizing DIY health tracking by making physiological sensors to measure the body’s biosignals accessible to all. Combine the two and it has never been easier to create revolutionary smart wearable concepts to life.

With Printoo, a number of inputs were already available: accelerometer, temperature sensor, capacitive and light sensors. BITalino’s modules for Electromyography (EMG), Electrodermal Activity (EDA) and Electrocardiogram (ECG) can be easily connected to Printoo through a flexible coupling board. Combine these inputs with flexible LEDs (in strip or matrix form), electrochromic displays, a sound buzzer, as well as Bluetooth Low Energy connectivity, and the possibilities are endless.

BITalino – Create projects with physiological sensors – [Link]



Small, light health patch with enhanced accuracy

smalllighthe

by Hanne Degans:

Holst Centre and IMEC have unveiled a prototype flexible health patch weighing just 10g – half the weight of current products. The patch uses real-time electrocardiogram (ECG), tissue-contact impedance and accelerometer information to accurately monitor physical activity. Thanks to advanced system in package (SiP) technology from ShinkoElectric Industries, the electronics module measures less than two by two centimeters. The high accuracy algorithms, low power consumption, and small size and weight make it ideal for consumer applications.

Small, light health patch with enhanced accuracy – [Link]

Single-lead Heart Rate Monitor Analog Front End

05b776acae6e2bfd28d9baf525589318.media.600x542

Analog Device’s AD8232 is an integrated signal conditioning block for ECG and other biopotential measurement applications. It is designed to extract, amplify, and filter small biopotential signals in the presence of noisy conditions, such as those created by motion or remote electrode placement. This design allows for an ultralow power analog-to-digital converter or an embedded microcontroller to acquire the output signal easily.

The device can implement a two-pole high-pass filter for eliminating motion artifacts and the electrode half-cell potential. This filter is tightly coupled with the instrumentation architecture of the amplifier to allow both large gain and high-pass filtering in a single stage. An uncommitted operational amplifier enables the creation of a three-pole low-pass filter to remove additional noise. The user can select the frequency cutoff of all filters to suit different types of applications. [via]

Single-lead Heart Rate Monitor Analog Front End – [Link]

Simple DIY ECG + Pulse Oximeter

diy-ecg-pulse-oximeter-lm324-opamp-sound-card-525x393

Scott W Harden writes:

I re-vamped my DIY ECG project. This new project is fully documented and uses extremely common and cheap parts, all of which could be purchased at RadioShack. It serves at both an ECG *and* a pulse oximeter, depending on which leads are attached. It uses a single chip (LM324, a quad operational amplifier) with a virtual ground to eliminate the need for a negative voltage. As a pulse oximeter with a 12V supply it outputs clean 10V swings when pulses occur. It’s intentionally unsophisticated, and made to be easy to replicate by anyone interested in electronics. Although you could view its output on an oscilloscope, it’s designed to be output into a PC sound card for recording (if attenuated to microphone levels). I even describe how to spectrally process the data on the computer to clean it up, downsample it, and graph it in Excel or with a Python script.

Simple DIY ECG + Pulse Oximeter – [Link]



Carry a Chip in your Heart

ECG

Imec demonstrated a low-power (20µW), intra-cardiac signal processing chip for the detection of ventricular fibrillation at this week’s International Solid State Circuits Conference (ISSCC 2013) in San Francisco with Olympus. An important step toward next-generation Cardiac Resynchronization Therapy solutions, the new chip delivers innovative signal processing functionalities and consumes only 20µW when all channels are active, enabling the miniaturization of implantable devices. [via]

Robust and accurate heart rate monitoring of the right and left ventricles and the right atrium is essential for implantable devices used in cardiac resynchronization therapy, and accurate motion sensor and thoracic impedance measurements to analyze intrathoracic fluid are critical for improving clinical research and analysis of intracardiac rhythm. Extremely low power consumption is also necessary to reduce the size of cardiac implants and improve the patient’s quality of life.

Carry a Chip in your Heart – [Link]

Saelig Announces imPulse(tm) ECG Personal Monitor To Be Launched at Electronica 2012

Pittsford, NY:  imPulse(tm) is a personal, iPhone-compatible, handheld ECG Touch Monitor that will be introduced at this year’s Electronica Show in Munich, Germany, designed using unique EPIC touch sensors.  Created by the sensorʼs manufacturer Plessey Semiconductors,  imPulse(tm) is aimed at the home health market, and will allow the routine, quick and accurate recording of ECG signals outside of the medical environment – without the need for conductive gel or skin preparation. Continue reading Saelig Announces imPulse(tm) ECG Personal Monitor To Be Launched at Electronica 2012
