15V 1A Dual Output Flyback DC-DC Converter

+/-15V 1A Dual output DC-DC converter is a tiny board built using Transformer from Renco and LM2587-ADJ IC from Texas instrument.  Input supply 18-36V DC.  The LM2587 regulators is monolithic integrated circuit specifically designed for fly back, step-up (boost), and forward converter applications. The power switch is a 5.0A NPN device that can stand-off 65V. Protecting the power switch are current and thermal limiting circuits, and an under voltage lockout circuit. This IC contains a 100 kHz fixed frequency internal oscillator that permits the use of small magnetics. Other features include soft start mode to reduce in-rush current during start up, current mode control for improved rejection of input voltage and output load transients and cycle-by-cycle current limiting. An output voltage tolerance of ±4%, within specified input voltages and output load conditions, is ensured for the power supply system.

Features

  • Supply Input 18-36V DC
  • Output +/-15V DC, 1Amp
  • On board trimmer potentiometer for Fine voltage adjust
  • Operation Frequency 100 KHz

15V 1A Dual Output Flyback DC-DC Converter – [Link]

Isolated 24V to 12V 10W Flyback Power Supply

maximintegrated.com power supply experts have a reference design of a 24V to 12V flyback converter.

Maxim’s power supply experts have designed and built a series of isolated, industrial power-supply reference designs. Each of these power supplies efficiently converts 24V into useful voltage rails at a variety of power levels. Every power rail is isolated with a readily available transformer from multiple, global vendors, providing for quick, convenient transformer selection. Each design has been tested for load and line regulation, as well as efficiency and transient performance. As with all Maxim reference designs, the BOM, schematics, layout files, and Gerber files are all available. In addition, boards are available for purchase; most boards feature through-hole pins for immediate board placement and accelerated prototyping.

Isolated 24V to 12V 10W Flyback Power Supply – [Link]

LT8315 – 560VIN Micropower No-Opto Isolated Flyback Converter

The LT8315 is a high voltage monolithic flyback regulator that simplifies the design of an isolated DC/DC converter. By sampling the reflected isolated output voltage across the third winding on the power transformer, the part requires no opto-isolator or LT1431 for regulation. The LT8315 operates over an 18V to 560V input voltage range, has a 0.30A/630V integrated power switch and delivers up to 15 watts of output power, ideal for electric vehicles and battery stacks, as well as off line, automotive, industrial and medical applications.

LT8315 – 560VIN Micropower No-Opto Isolated Flyback Converter – [Link]

100Vin, 5W out regulator uses primary-side control

160919edne-linear8303

LT8303 is a monolithic flyback regulator in a TSOT-23 package that simplifies the design of isolated DC/DC converters. By sampling the isolated output voltage directly from the primary-side flyback waveform, the part requires no opto-isolator, LT1431 or third winding for regulation. by Graham Prophet @ edn-europe.com

The LT8303 operates over a 5.5V to 100V input voltage range, has a 0.45A/150V integrated DMOS power switch and delivers up to 5W, suiting it for a range of telecom, datacom, automotive, industrial, medical and military applications. The output voltage is set with one external resistor and the transformer turns ratio. Several off-the-shelf transformers are identified in the data sheet. The LT8303 operates in boundary mode, which is a variable frequency current mode control switching scheme, typically resulting in ±5% output voltage regulation over the full line, load and temperature range. Boundary mode enables the use of a smaller transformer compared to equivalent continuous conduction mode designs. The high level of integration and the use of low ripple Burst Mode operation result in a simple to use, low component count and high efficiency application solution for isolated power delivery.

100Vin, 5W out regulator uses primary-side control – [Link]

LT8331 – Low IQ Boost/SEPIC/ Flyback/Inverting Converter

8331

Linear Technology Corporation announces the LT8331, a current mode step-up DC/DC converter with an internal 500mA, 140V switch. It operates from an input voltage range of 4.5V to 100V, making it suitable for use with a wide range of input sources found in industrial, transportation and avionic applications. The LT8331 can be configured as either a boost, SEPIC, flyback or inverting converter. Its switching frequency is programmable from 100kHz to 500kHz, enabling designers to minimize external component sizes.  Burst Mode® operation reduces quiescent current to only 6µA while keeping output ripple below 20mVP-P. The combination of a high voltage MSOP-16E package and tiny externals ensures a very compact footprint while minimizing solution cost.

LT8331 – Low IQ Boost/SEPIC/ Flyback/Inverting Converter – [Link]

LT8331- Low IQ Boost/SEPIC/ Flyback/Inverting Converter

8331

The LT8331 is a current mode step-­up DC/DC converter with an internal 500mA, 140V switch. It operates from an input voltage range of 4.5V to 100V, making it suitable for use with a wide range of input sources found in industrial, transportation and avionic applications. The LT8331 can be configured as either a boost, SEPIC, flyback or inverting converter. Its switching frequency is programmable from 100kHz to 500kHz, enabling designers to minimize external component sizes. Burst Mode operation reduces quiescent current to only 6µA while keeping output ripple below 20mV. The combination of a high voltage MSOP­-16E package and tiny externals ensures a very compact footprint while minimizing solution cost.

LT8331 – Low IQ Boost/SEPIC/ Flyback/Inverting Converter – [Link]

500mA, 140V Boost/SEPIC/Flyback/Inverting DC/DC Converter with IQ= 6uA



8331

Linear Technology Corporation announces the LT8331, a current mode step-up DC/DC converter with an internal 500mA, 140V switch. It operates from an input voltage range of 4.5V to 100V, making it suitable for use with a wide range of input sources found in industrial, transportation and avionic applications. The LT8331 can be configured as either a boost, SEPIC, flyback or inverting converter. Its switching frequency is programmable from 100kHz to 500kHz, enabling designers to minimize external component sizes. Burst Mode® operation reduces quiescent current to only 6µA while keeping output ripple below 20mVP-P. The combination of a high voltage MSOP-16E package and tiny externals ensures a very compact footprint while minimizing solution cost.

500mA, 140V Boost/SEPIC/Flyback/Inverting  DC/DC Converter with IQ= 6uA – [Link]



50,000V High Voltage Power Supply

FCO96BGIDUR7T94.MEDIUM

by Victor8o5 @ instructables.com:

This high voltage power supply has been designed to output a fixed voltage of around 50kV, it could easily be converted to an adjustable supply by connecting a variac in case of using transformers or by adding some extra circuitry to regulate the power going in. I initially thought about a high frequency PWM to regulate the power going into the capacitors, but I abandoned the idea. I found that adjusting the frequency is enough to make the voltage vary by a significant amount, allowing some control over it, this happens because the flyback must operate at a certain frequency in order to maximize the output.

50,000V High Voltage Power Supply – [Link]
