Tag Archives: FM

Simple FM Radio


by electronics-diy.com:

This is one of my favorite radio builds just because of how simple it is and how well it is able to pick up a lot of FM radio stations. I have browsed the world in search of a one transistor FM receiver. I have seen a couple but they were always attached to some sort of added device, such as another IC or another transistor for amplification in the receiver itself. Through my continued quest of searching for that too good to be true one transistor, I happened to run across a super-regenerative receiver, by Charles Kitchin, famous for his vast knowledge of regenerative designs. I printed out the schematic and made it. It turned out extremely well.

Simple FM Radio – [Link]

Raspberry Pirate Radio


by Sam Freeman and Wynter Woods @ makezine.com:

This simple hack turns your Raspberry Pi into a powerful FM transmitter! It has enough range to cover your home, DIY drive-in movie, a high school ball game, or even a bike parade (depending on the stragglers).

PiFM software not only boldly enhances the capability of your Pi, but does so with nothing more than a single length of wire. This hack starts with the absolute minimum you need to run a Raspberry Pi — an SD card, a power source, and the board itself — and adds one piece of wire. It’s the coolest Pi device we’ve ever seen with so few materials.

Raspberry Pirate Radio – [Link]

Mini FM transmitter


electronics-diy shows you how to easily make a mini FM transmitter:

It transmits FM waves so you could easily receive the signals on your mobile phone, radios, etc. As the name and the picture indicates it is very small and is approximately the size of a 9v battery clip. With this FM transmitter you could start your own mini FM station. The circuit uses BC547 transistor to amplify the signal and then frequency modulate it. It uses “frequency modulation

DIY portable FM transmitter

Stream your music to your entire home !!!

Zola Lab – Portable FM Transmitter

Lipo 3.7v
Sparkfun Circular LED
Adafruit Si4713 FM Radio Transmitter
2 x Arduino Pro mini
Sparkfun Rotary Encoder
Catalex 4-Digits 7seg Display
Lipo Charger

On the top there is a: P2 audio input, a switch on/off, and a female micro-usb for charging Lipo.


DIY portable FM transmitter – [Link]

The Ultimate FM Transmitter (Long Range Spybug)


by ASCAS @ instructables.com:

Have you ever wanted to broadcast your own radio station within the neighborhood? Ever get curious on where people get those “Surveillance Bugs” from spy and action movies? This small and simple FM transmitter is the toy that geeks have always wanted.

FM transmitters can be complicated to build, that’s why I’m teaching you how to make a foolproof FM transmitter. There’s no need to buy kits, this tutorial includes the PCB layout and the schematics. It has a range of up to 1/4 mile or more. It’s great for room monitoring, baby listening and nature research.

The Ultimate FM Transmitter (Long Range Spybug) – [Link]

FM Modulation/de-modulation Circuit


by brmarcum @ instructables.com:

I got the idea for this circuit from one of my professors at Washington State University. However, the frequencies used in that project would not have allowed for passing higher frequency audio, e.g. 2kHz+. So I built this by modifying the carrier and signal frequencies, using only the Digilent Analog Discovery and the Analog Parts Kit. It should be noted that this circuit is primarily for educational purposes. Also note that there is no radio transmission here either. FM doesn’t necessarily mean radio waves have to involved.

Throughout this Instructable I will be going through some of the functions and features of the Analog Discovery, but it will not be an exhaustive tutorial.

FM Modulation/de-modulation Circuit – [Link]

Mini Audio Transmitter


lamefreaks @ instructables.com writes:

In this instructable I’m going to show you how to build your own portable audio transmitter. This transmits FM waves so you could easily get the signals on your mobile phone, radios, etc. As the name and the picture indicates it is very small and is approximately the size of a 9v battery clip.

Mini Audio Transmitter – [Link]
