Using the OpenScope MZ in LabVIEW

This project will show how to use your OpenScope MZ in LabVIEW. by Austin Stanton @ hackster.io:

In this tutorial, we will go over how to connect an OpenScope MZ to LabVIEW. To do so, I will be walking you through some example VIs that I made. These examples allow you to access the oscilloscope and Wavegen/DC power supply functions of the OpenScope as well as the GPIO pins and the Logical Analyzer.

Using the OpenScope MZ in LabVIEW – [Link]

Display Arduino analog input using LabVIEW

Zx Lee shared detailed instructions of how to display the Arduino measurements using LabVIEW:

To get started, I will explain what is actually going on in Arduino. In this project, I am using an Arduino Nano to acquire signals and send the data to PC. As mentioned earlier, two analog input channels (A0 & A1) will be used to measure input signals. To ensure an accurate measurement is performed at fixed sample rate, the Arduino is configured to wait the predefined interval before taking a measurement and send to PC serially. The concept used is similar to the BlinkWithoutDelay example in Arduino. The benefit of using this method is that there is a while loop that always checks if it has crossed the desired interval. If it is reached, it will take the measurement, else it will skip and you can make it to work on other task.

Display Arduino analog input using LabVIEW – [Link]

8 Channel RS485 Relay Board

8-channel-rs485-driven-relay-board-img

This project helps you control 8 relays using RS485 link with the help of a PC. This kit can effectively convert  a standard PC to a powerful   PLC ( programmable logic controller ). At the PC end , you will need to use our RS232 to RS485 Interface – C020 or any other suitable RS232 to RS485 Converter.

The project can offer a low-cost serial relay contact interface, easy to use with Visual Basic, Basic, C, Labview, Testpoint, or other high level languages that allow access to a serial port.

You can simply use the accompanying software provided with this project or issue control commands using any popular Terminal Port software available on the net.

The Serial port on the computer should be configured to 2400 baud – 8 bit words – 1 stop bit – no parity

8 Channel RS485 Relay Board – [Link]
