Tag Archives: Nixie

Wireless Nixie Thermometer

FI251XKICRXVI4O.MEDIUM

by christian.ich.7 @ instructables.com:

The Target of this Project was to learn how to use different functions of the atmega:

• Connecting two Atmegas with a wireless connection
• Each Atmega has a Thermometer (DS1621) to read the actual temperature
• Use the sleep Mode of an Atmega
• Controlling a Nixie bargraph In-13

Wireless Nixie Thermometer – [Link]

Nixie Tube Clock

20150525_195643

by Pete Mills :

If you’ve poked around the internets where electronics hobbyists collect, it is likely that you are acutely aware of our incontrovertible affinity for building timekeeping clocks. It is similarly unlikely that you have been able to evade the plenitude of nixie tube based projects. There is a reason for this.

Nixie tubes are cool. They have great aesthetic appeal with their difficult-to-photograph, warm orange glow, and dem curvy numerals. They add an organic je ne sais quoi to a hobby with ostensibly digital design cues. Further, they pose technical challenges in the way of producing and switching the ~175 V DC needed to light each tube element. And as far as I am aware, there are no new nixie tubes being produced; as such, procurement can be a challenge unto itself. My N.O.S. nixies came from Russia thru Ebay, and only 3 were duds. Incidentally the seller replaced those 3, FOC.

Nixie Tube Clock – [Link]

Nixie Tube Clock

20150525_195643

by Peter @ petemills.blogspot.in:

Nixie tubes are cool. They have great aesthetic appeal with their difficult-to-photograph, warm orange glow, and dem curvy numerals. They add an organic je ne sais quoi to a hobby with ostensibly digital design cues. Further, they pose technical challenges in the way of producing and switching the ~175 V DC needed to light each tube element. And as far as I am aware, there are no new nixie tubes being produced; as such, procurement can be a challenge unto itself. My N.O.S. nixies came from Russia thru Ebay, and only 3 were duds. Incidentally the seller replaced those 3, FOC.

Nixie Tube Clock – [Link]

IN-12 Nixie Clock

nixie

by tomasz.watorowski @ mightydevices.com:

A time has come for me to say ‘hello’ to the mid-XX century technology of Neon numerical displays, also known as Nixie tubes. Despite being quite hard to obtain and utilize I’ve decided to make a nice looking clock which (hopefully) would make a perfect Christmas present, and since the Christmas is all about sharing I thought It would be nice to go Open Source about it.

After few weeks of work I’ve ended up with neat single board design that makes the whole thing cheaper and easier to manufacture than the usual double board solutions (separate board for nixie lamps/divers, and another for microcontroller, power supply, high voltage dc/dc conversion, etc.). All of the circuitry is laid out on the back of the clock so it does not interfere with the old-school look of the Nixie displays.

IN-12 Nixie Clock – [Link]



IN-12 nixie clock

FQ2MJ06I2I472K2.MEDIUM

by pinomelean @ instructables.com:

Ever since i discovered nixies i wanted to make a clock with them, but all the designs i found were for 4 or more nixies, required a custom power supply and a complicated driving system.

As the cheap guy i am, i didn’t want to buy lots of nixies or components to make such complicated circuits. And after ages looking for a simple clock design i came up with this page.

IN-12 nixie clock – [Link]

Flashing a Nixie with an Arduino

nixie-600x398

Kevin Rye writes:

I’m in the very early stages of prototyping a nixie clock. I picked up some MJE340 power transistors to switch on some IN-3s. I can then use a digital pin on my Arduino to turn on the IN-3s through the transistor. I’ll then have myself a blinking colon for my nixie tube clock.

[via]

Flashing a Nixie with an Arduino – [Link]

Nixie tube clock

IMG_20140518_115041-600x337

Tom Cousins of DOAYEE made this DIY nixie tube clock:

Below is the schematic for the project, as you can see I’m using 6 IN12 nixie tubes, each with it’s own 74141 nixie tube driver. These drivers are great! They simply connect directly to the nixies and display whatever 4 bit binary number you give them (if you give them anything above 9 they blank the display – hence why I use the number 10 in my code to blank the nixies). Because they take in a simple 4 bit binary number, I can hook them directly up to some shift registers to drive them, in my case I used 3 74HC595 shift registers (available everywhere), because they can be “daisy chained

High Voltage Power Supply for Nixie Tube Projects

default

Jan Rychter @ jan.rychter.com designed his own Nixie power supply that except the high voltage has two voltage outputs to power the logic circuitry, he writes:

This project is a HVPSU (High-Voltage Power Supply) that generates up to 220V from a 12V input. In addition to that, it also provides 2*Vout (so, up to 440V, for dekatrons), and two outputs for powering digital logic: 5V and 3.3V. The primary HV boost circuit reaches 88% efficiency when going from 12V to 185V at 55mA, with a 3% output ripple.

I designed it because I couldn’t find anything that would make sense for my Nixie projects. There are plenty of tiny power supply modules available on eBay, but most of them end up being impractical: no 3.3V (for my microcontroller) and 5V (for my 74141 nixie drivers), no mounting holes, no >400V output for powering dekatrons. Some supplies make a token gesture towards practicality by sticking a 7805 on the same board, but you quickly find out that the current draw of 6×74141 is enough to require a large heat sink on a 12V-powered 7805 (one 74141 consumes 12.5mA!). This means that instead of a single-board power supply you end up routing your input power all over the place, implementing your power supply in several places.

High Voltage Power Supply for Nixie Tube Projects – [Link]

HV Nixie DC-DC Power Supply

photo_1_th

Nixie tubes need about ~180Vdc to light up and thus on most devices a DC-DC converter is needed. We designed here a simple DC-DC switching regulator capable of powering most of Nixie tubes.

The module is based on the MAX1771 Step-Up DC-DC Controller. This controller works up to 300kHz switching frequency and that allows the usage of miniature surface mount components. It accepts an input voltage from 2 to 16.5V and the output is factory configured to 12V. In this module the output voltage is configured higher at ~180Vdc using external resistors and a potentiometer.

HV Nixie DC-DC Power Supply – [Link]

Valve & Nixie Socket Calculator

Sockulator

desmith.net hosts a nice little script to generate socket footprints for various CAD packages:

This program lets you determine the pin circle diameter of a tube base from measurements more readily made with a micrometer. The data should be entered in millimetres and the results will be in the same units.  Script output for a package definition of the resulting socket can be generated for several CAD packages. Create a disk file from the output script and execute it in the relevant package – for Eagle execute the script as a SCR from the library editor.

Valve & Nixie Socket Calculator – [Link]
