Dual Relay Board Using SMD Components

  • Rajkumar Sharma
  • 9630
    Views
  • easy
  • Tested

Dual channel Compact  Relay driver module can be controlled by feeding 2-12V trigger voltage, Very useful project for application like Micro-Controller based projects, Remote controller, Lamp on Off, and any circuits which required isolated 5A current and high voltage switching by applying any TTL or CMOS level voltage. Two LED works as operation indicator, 3 pins screw terminals to connect load.  Relay provides both normally open and normally closed switching.

Note: Board is made only for low voltage switching applications.

Specifications

  • Input: 12 VDC @ 84 mA
  • Output: Two SPDT relay
  • Relay specification: 5 A @ 60 VAC
  • Trigger level: 2 to 12 VDC
  • Header connector for connecting power and trigger voltage
  • LED on each channel indicates relay status
  • Power Battery Terminal (PBT) for easy relay output connection

Schematic

Parts List

Photos

PCB
