I can figure out the regulator but not the IR2110 chip I think that this one is correct because in the image on the datasheet the VDD and VCC are connected and they have a shared decoupling capacitor arrangement, but in my case the VDD is separate from VCC and so they should both (the VDD and the VCC) have their own decoupling capacitor arrangements. Is that correct thinking?! I'm not very good at reading datasheets can you tell me what is good/will work please Mr Alec_t
just need the green light then I can get going with the PCB design, thanks
PS the GND symbol over INVETER INPUT should be over next to the 12volt connector!
