LE-37M – 3.5″ Miniboard with Intel® 8th Gen Core™ H-series Processor

LE-37M – 3.5″ Miniboard with Intel® 8th Gen Core™ H-series Processor

1630
Views
0 Comments

Taiwan Commate Computer Inc.(COMMELL), the worldwide leader of Industrial Single Board Computers, unveiled LE-37M 3.5 inch Miniboard embedded system board based on 8th generation Intel® Core™ H-series processors.

The LE-37M 3.5 inch Miniboard platform is designed for the 8th generation Intel® Core™ H-series processors in the FCBGA1440 sockets.support DDR4 memory (Two DDR4 SO-DIMM 2666 MHz up to 32GB).

LE-37M SBC Bottom

The platform is based on Intel® UHD Graphics, this GPU offers 24 execution units (EUs) clocked at up to 1150Mhz(depending on the CPU model), The revised video engine now decodes H.265/HEVC completely in hardware and thereby much more efficiently than before. Displays can be connected via 1 VGA, 1 LVDS, 1 HDMI and one DP port up to three displays can be controlled simultaneously. LE-37M offers lots of features including high-speed data transfer interfaces such as 4 x USB3.1 Gen2 and 2 x SATA3, equipped with dual Gigabit Ethernet, and comes with PS/2 port, 2 x RS232 and 2 x RS232/422/485, 4 x USB2.0, Intel® High Definition Audio, and 1 MiniPCIe socket(Supports mSATA), 1 M.2 (Key E).

Features

  • CPU: Intel® 8th Gen Core™ H-series Processor in the FCBGA1440 sockets.
  • Memory: Two DDR4 2666 MHz SO-DIMM up to 32 GB, support Non-ECC, unbuffered memory.
  • Chipset: Intel® QM370 chipset.
  • Integrated Graphics: Intel® UHD Graphics.
  • LVDS interface: Onboard 18/24-bit single/dual channel LVDS connector with +3.3V/+5V/+12V supply
  • Display port interface: Onboard Display port connector. (Only LE-37M5)
  • HDMI interface: Onboard HDMI connector.
  • VGA interface: Onboard DB15 VGA connector.
  • LAN Interface: 1 x Intel® i219-LM Gigabit PHY LAN(Support iAMT 12.0), 1 x Intel® i210-AT Gigabit LAN.
  • Serial ATA: Support 2 x SATA3.
  • Audio: Realtek ALC262 High Definition Audio.
  • Internal I/O: 2 x SATA3, 2 x RS232,  2 x RS232/422/485, 4 x USB2.0, 1 x LVDS, 1 x LCD inverter, 1 x GPIO, 1 x Audio, 1 x PS/2, 1 x SMBus.
  • Rear I/O: 1 x DisplayPort(Only LE-37M5), 1 x HDMI, 1 x VGA, 4 x USB3.1 Gen2, 2 x LAN.
  • Extended interface: One PCIE Mini card (Support mSATA), one M.2 (Key E).
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface.
  • Power requirement: DC input 9~35V.

more info: www.commell.com.tw
