Texas Instruments TPSM846C24 High-Density Step-Down Power Module

Texas Instruments TPSM846C24 High-Density Step-Down Power Module

1348
Views
0 Comments

Texas Instruments TPSM846C24 35A Power Modules offer a fixed frequency and incorporate the controller, power MOSFETs, inductor, and associated components into a thermally enhanced, surface-mount package. To set the operating parameters of the module, the user supplies the input and output capacitors as well as a few other passive components. A two-phase power solution can be achieved by configuring two modules to work in parallel up to 70A with current sharing. The TPSM846C24 operates at an IC Junction Range of –40°C to +125°C. The device provides a 15mm × 16mm component footprint that is easy to solder onto a printed circuit board and allows a compact, point-of-load design.

TI’s PSM846C24, available from Mouser Electronics, is a fixed-frequency, 35 A, step-down power module that incorporates a controller, power MOSFETs, inductor, and associated components into a thermally enhanced, surface-mount package. Setting the operating parameters of the module requires just input and output capacitors as well as a few other passive components.

The module is supported by the TPSM846C24EVM-006 and TPSM846C24EVM-007 evaluation modules. Both evaluation modules provide test points and jumpers to facilitate easy testing. The TPSM846C24EVM-006 contains a single TPSM846C24 module, while the TPSM846C24EVM-007 contains two TPSM846C24 modules working in parallel to enable up to 70 A output current.

Features

  • Complete Integrated 35A Power Solution
  • Power-Good Output
  • Pin Compatible With TPSM846C23 (PMBus)
  • Stackable up to 70A With Current Sharing
  • Output Voltage Range 0.5V to 2V
  • Output Voltage Accuracy as Tight as 0.5%
  • 15mm × 16mm Footprint (6.4mm Maximum Height)
  • 300kHz to 1MHz Switching Frequency
  • Synchronization to an External Clock
  • Differential Remote Sense
  • Prebias Output Monotonic Start-up
  • Fixed 3ms Soft-Start/Soft-Stop Time
  • Overcurrent Protection
  • Operating IC Junction Range: –40°C to +125°C
  • Operating Ambient Range: –40°C to +105°C
  • Enhanced Thermal Performance: 8.7°C/W
  • Meets EN55022 Class A Emissions

For more information, visit www.mouser.com/ti-tpsm846c24-power-modules.
