12V to 28V Step Up DC-DC Converter

  • Rajkumar Sharma
  • 11604
    Views
  • easy
  • Tested

12V-to-28V-StepUp-Converter-G054

The Step-Up DC-DC Converter project provides 28V, 175mA output with input of 12V DC. The  MC34063A IC is heart of the project from On semiconductor. The MC33063A is a monolithic control circuit containing the primary functions required for DC-DC converters, This device consist of an internal temperature compensated reference, comparator, controlled duty cycle oscillator with an active current limit circuit, driver and high current output switch. This IC specially designed to be incorporated step-down, step-up, and voltage-inverting applications with minimum number of external components.

Features

  • Input 12V DC
  • Output 28V, 175mA
  • Output Fine Adjustable By On-board Preset
  • Header Connector for Output/Input Connections
  • Low Standby Current
  • On Board Filter To Provide Low Ripple Output
  • PCB Dimensions 28mmX33MM

Schematic

12V-to-28V-StepUp-Converter-SCH

Parts List

12V-to-28V-StepUp-Converter-BOM

PCB
