RC Signal Monitor Using Bargraph & RC Switch using Relay

RC Signal Monitor Using Bargraph & RC Switch using Relay

4.229
Views
0 Comments

The versatile Bar-Graph SMD components based R/C monitor & R/C switch is a great tool for R/C hobbyist R/C modeller and DIY robotics. Tiny Bar-Graph displays provide a Red color bright, easy to read display of Radio Control (R/C) signal from 1mS to 2mS. The Barograph RC Signal reader is based on PIC16F886 microcontroller. This high performance measurement device, provides unique capabilities and can be used in various applications like Radio Signal Monitor, Robotics, Machine Control, RC Remote Tester, RC Signal ON/OFF switch by connecting Relay board or Solid state relay at output of any suitable LED. Solder Jumpers provided on bottom side of PCB to select particular output to interface with Relay or Solid state Relay.

RC Signal Monitor Using Bargraph & RC Switch using Relay – [Link]
