Voltage Controlled Oscillator with Isolated Output
https://www.electronics-lab.com/project/voltage-controlled-oscillator-with-isolated-output/
Precision Oscillator: 1–31kHz programmable range. Compact board acts as fixed-frequency or VCO.
Half-Bridge Driver with Inbuilt Oscillator
https://www.electronics-lab.com/project/half-bridge-driver-with-inbuilt-oscillator/
This project is a Half Bridge with Inbuilt Oscillator utilizing the NCP1392B MOSFET driver and IRF540 MOSFETs for half-bridge topology applications. It allows for adjustable operating frequency from 25 kHz to 100 kHz with a trimmer potentiometer. The project includes brown-out protection, a PFC delay timer, and fixed dead time to improve performance. Designed for low-voltage applications up to 36V and 3A load current with forced air cooling, it can be modified for high-voltage use up to 400V by changing components like capacitors and MOSFETs. The operating frequency can be tuned up to 480 kHz depending on component values, with recommendations to consult the datasheet for optimal performance in higher frequency applications.
Clock Multiplier – Crystal Frequency Generator using PT7C4511
https://www.electronics-lab.com/project/clock-multiplier-crystal-frequency-generator-using-pt7c4511/
This is an easy-to-build project and it is the most cost-effective and high-performance frequency multiplier, which instigates analog phase lock loop techniques. The circuit provides high-quality, high-frequency output from lower frequency crystal or clock input. The project can be used as a crystal frequency oscillator, clock multiplier and frequency translation. Using phase-locked-loop (PLL) techniques, the […]
Voltage-Controlled Pulse Width Modulator (PWM) – PWM Signal Generator
https://www.electronics-lab.com/project/voltage-controlled-pulse-width-modulator-pwm-pwm-signal-generator/
This is an easy-to-use voltage to PWM converter. The project occupies very little space. The circuit is built using the versatile silicon timing device LT6992-1 chip. Pulse Width Modulation (PWM) Controlled by Simple 0V to 1V Analog Input, multiturn trimmer potentiometer provided to adjust the duty cycle 0 to 100 %. The circuit also has […]
Multiphase Oscillator with 40% Spread Spectrum Frequency Modulation and 250Khz Output Frequency
https://www.electronics-lab.com/project/multiphase-oscillator-with-40-spread-spectrum-frequency-modulation-and-250khz-frequency-output/
This is a precision, low power, and easy-to-use oscillator that provides multiphase outputs. The output frequency of the project is set to 250Khz, with 40% spread spectrum. The oscillator frequency can be set by resistor R1, and the spread spectrum can be changed using R3. The master oscillator is controlled by the RSET resistor R1 […]
1Khz to 20Mhz Low Power Oscillator
https://www.electronics-lab.com/project/1khz-to-20mhz-low-power-oscillator/
This is a precision, low power oscillator that occupies very little space. The oscillator frequency is adjustable using an onboard multi-turn trimmer potentiometer. The output of the circuit is very accurate and has a 1.5% frequency error. The project operates with a single 5V power supply and provides a rail-to-rail, 50% duty cycle square wave […]
