Sjaak has published a new PCB build, uC controlled dummy load:
With no snow outside I finally got around to solder the 3rd PCB. It is the second revision of a microcontroller dummy load. It is loosely based on the arachnidlabs uc:load. It uses the same base ciruit and adds a microcontroller (PIC16F1825), rotary encode switch, external powersupply and offcourse a 128×32 OLED.
UCload new PCB build – [Link]
