The board has been design around INA217 low distortion, low noise instrumentation amplifier. The INA217 is ideal for low-level audio signals such as balanced low-impedance microphones. Many industrial, instrumentation, and medical applications also benefit from its low noise and wide bandwidth. Unique distortion cancellation circuitry reduces distortion to extremely low levels, even in high gain. The INA217 provides near-theoretical noise performance for 200Ω source impedance. The INA217 features differential input, low noise, and low distortion that provides superior performance in professional microphone amplifier applications. An OPA2137 op-amp used as a feedback to eliminate the offset voltage. Phantom power is not part of the circuit its just for reference.
Supply Dual +/-15V DC
Output Unbalance Single Ended
PR1 Gain Adjust G=1+10000/Rg PR1
Tiny Professional Microphone Preamplifier – [Link]
