Phase-Shifted Full-Bridge PWM Controller Module – LM5046 Breakout Board

Phase-Shifted Full-Bridge PWM Controller Module – LM5046 Breakout Board

554
Views
0 Comments

This is a Phase-Shifted Full-Bridge PWM LM5046 carrier board that contains all of the features necessary to implement a phase-shifted full-bridge topology power converter. All inputs and outputs pins are accessible using the header connector. High efficiency DC-DC converter can be created using LM5046 carrier board + External H-Bridge and Transformer. Refer to the datasheet of LM5046 and schematic to configure the frequency, current feedback, delays, etc.

Phase-Shifted Full-Bridge PWM Controller Module – LM5046 Breakout Board – [Link]
