ON Semiconductor NFAQ1060L36T Intelligent Power Module (IPM)
NFAQ1060L36T - Three-phase 10 A / 600 V IGBT module with integrated drivers using DBC substrate. The NFAQ1060L36T is a fully-integrated inverter power stage consisting of a high-voltage driver, six IGBT’s and a thermistor, suitable for driving permanent magnet synchronous (PMSM) motors, brushless-DC (BLDC) motors and AC asynchronous motors.
NFAQ1060L36T – Three-phase 10 A / 600 V IGBT module with integrated drivers using DBC substrate.
The NFAQ1060L36T is a fully-integrated inverter power stage consisting of a high-voltage driver, six IGBT’s and a thermistor, suitable for driving permanent magnet synchronous (PMSM) motors, brushless-DC (BLDC) motors and AC asynchronous motors. The IGBT’s are configured in a 3-phase bridge with separate emitter connections for the lower legs for maximum flexibility in the choice of the control algorithm.
The power stage has a full range of protection functions including cross-conduction protection, external shutdown, and under-voltage lockout functions. An internal comparator and reference connected to the over-current protection circuit allow the designer to set the over-current protection level.
Features
- Three-phase 10 A / 600 V IGBT module with integrated drivers using DBC substrate
- Typical values: VCE(sat) = 1.9V, VF = 2.4V, ESW = 400 µJ at 10 A
- Compact 29.6 mm x 18.2 mm dual in-line package
- Adjustable over-current protection level
- Integrated bootstrap diodes and resistors
- Thermistor
- Short lead length (3.4mm, module bottom to pin end)
Benefits
- Good heat dissipation with DBC (low thermal resistance)
- Using the latest tech to optimize loss, good EMI
- PCB size reduce with compact sized packaged
- Adjustable OCP level
- Multi function integrated for compact design, cost optimization
- More accurate module temperature measurement by embedded NTC
- Module assembly to PCB more closely to reduce stress from vibration
