Isolated Analog Input Module v2
https://www.electronics-lab.com/project/isolated-analog-input-module-v2/
This Isolated Analog Input module is designed for industrial applications, optically isolating 0−5V sensor signals to output 0−3.3V for microcontrollers. It uses a linear optocoupler (3750V isolation) and requires two separate 5V supplies. A simple resistor change allows it to accept 0−10V inputs.
Isolated Potentiometer and Switch Module using LOC110
https://www.electronics-lab.com/project/isolated-potentiometer-and-switch-module-using-loc110/
This Isolated Potentiometer Module provides isolated analog (0−3.3V from a 10K pot) and isolated switch inputs (via PC817 optocouplers) for industrial use. It uses a LOC110 linear optocoupler (3750V isolation) and an isolated DC-DC converter for a single 5V supply.
INA122 Single Supply Micropower Instrumentation Amplifier Module
https://www.electronics-lab.com/project/ina122-single-supply-micropower-instrumentation-amplifier-module/
This low-noise INA122 precision instrumentation amp is ideal for portable data acquisition. It supports single-supply (2.2V to 12V), features an on-board 2.5V reference, adjustable gain (10-10000), and is adaptable for strain gauge/pressure sensors.
High Voltage IGBT Module, Low-side Driver with Over-Current Protection and Fault/Enable
https://www.electronics-lab.com/project/high-voltage-igbt-module-low-side-driver-with-over-current-protection-and-fault-enable/
This IGBT driver module is a low-side gate driver that features integrated over-current protection. The primary functions of this module are its built-in over-current protection and enable/fault output capabilities. The board’s main components include the gate driver chip (1ED44176N01F), an SMD D2PK IGBT, and a current sense resistor. The chip is equipped with an over-current protection function, which has a typical threshold of 0.5V at the OCP (Over-Current Protection) point. When an over-current condition occurs, the driver output is automatically switched off. Simultaneously, the EN/FLT (Enable/Fault) pin is internally pulled down, and an internal current source charges the capacitor (C4) connected between the FLTC and VSS pins to program the fault clear time. This module is capable of driving loads up to 1A and can drive higher current with forced air cooling. It can operate within a load power supply range of 80-400V DC, making it a reliable and efficient solution for various applications.
2 Channel MOSFET Module
https://www.electronics-lab.com/project/2-channel-mosfet-module/
This is a low profile and small size two-channel MOSFET board that can drive loads up to 2 x 3A. The Power Supply is 5V to 14V DC. Inputs and input Enable are TTL-level signals. The Output is by default enabled and an active high signal disables the output. Parallel Operation of Dual Outputs for […]
315Mhz RF Remote Transmitter – Arduino Compatible
https://www.electronics-lab.com/project/315mhz-rf-remote-transmitter-arduino-compatible/
This is a two-channel RF Transmitter unit that consists of, Atmega328 microcontroller, 2 Tactile switches with pull-down resistors, a programming port, and a 315Mhz RF transmitter module. It is an Arduino compatible open-source project that can be used for many RF transmitter applications. It is advisable to use 1 Foot hook-up wire as Antenna to […]
315Mhz RF Remote Receiver with On Board Relay – Arduino Compatible
https://www.electronics-lab.com/project/315mhz-rf-remote-receiver-with-on-board-relay-arduino-compatible/
This is one channel RF Receiver with an onboard Relay. The project can be used for ON/OFF control of AC or DC loads using an RF remote. It’s an Arduino compatible Receiver project that consists of, Atmega328 microcontroller, 315MHz RF Receiver, 12v Relay, 5V Regulator, etc. Arduino Pins Receiver: D3 Relay, D11 Data in from […]
600V – 30A IPM Module Carrier Board for Variable Frequency Drive (VFD)
https://www.electronics-lab.com/project/600v-30a-ipm-module-carrier-board-for-variable-frequency-drive-vfd/
This compact IPM module circuit provides a fully-featured, high-performance inverter output stage for AC Induction, BLDC, and PMSM motors. The circuit is based on FNA23060 chip which integrates the optimized gate drive of the built-in IGBTs to minimize EMI and losses, while also providing multiple on-module protection features: under-voltage lockouts, over-current shutdown, temperature sensing, and […]
