Using Low Cost Hardware to Enhance the User Experience


Ken Boak discuss how to build a graphic user interface using cheap TFT toughscreen displays. This article is about using their lowcost graphics co-processor IC to provide a neat user interface for any low-end microcontroller.

These days, when you can buy a 7″ tablet for $50, there is all the more reason for makers and hackers to want to become more engaged with up to the minute 7″ touchscreen technology for their latest projects. Fortunately, recent developments in hardware have made this both affordable and easy to do – to the point where no project is too small, not have a neat touchscreen interface – and sound too!

Using Low Cost Hardware to Enhance the User Experience – [Link]

UP/DOWN counter with memory using PIC16F88


Here is an up-down counter based on PIC16F88 and 7-segment display. The counter is using SMD components and features a RS-232 interface.

This is a simple digital counter with a serial rs-232 and a 7 segment display, i started this project to count items on some shelfs, but it can be used for anything, it is also, for the exception of the connectors, completely on SMD components.

UP/DOWN counter with memory using PIC16F88 – [Link]

MAGIC PIXEL – Bluetooth full color LED display


MAGIC PIXEL is a full color LED display able to show animations, scrolling texts, and video from a PC or Mac. The display can also be controlled using an Android or iOS device via bluetooth interface.

Magic Pixel is a universal and handy Bluetooth LED display, which we’ve been developing with focus on ease of use and effectivity. It can be used for displaying advertisement, information or just for fun. Magic Pixel is an ideal solution where effective and dynamic visualization of information is required.

MAGIC PIXEL – Bluetooth full color LED display – [Link]

Arduino Analog Signal Graphing on a TFT


dmainmon @ instructables.com has build an analog signal graphing project using Arduino Mega 2560 and a 2.8 TFT display. This project is used to display two analog signals as line and bar graphs. Touching the screen pauses the graph and opens a menu to adjust setting for the graphs.

The project uses an Arduino Mega 2560 and UNO R3 2.8 TFT Touch Screen to display two analog signals as line and bar graphs. One signal is a photo resistor and the second is an audio sample from an Adafruit Electret Microphone Amplifier with Adjustable Gain module. The audio signal is graphically displayed twice; once in the center using a line graph and also on the bottom with a bar graph. The top graph represents the photo resistor signal.

Arduino Analog Signal Graphing on a TFT – [Link]

Quantifying cooling system


Chris Palmer has built this coolometer project to measure the cooling effectiveness of various fan:

I was wondering about how I was going to calibrate the airflow reading but then realised that the flow rate is not actually what I am interested in. It is the cooling effect the airflow has, which is what I am directly measuring. The result is simply the extra power needed to maintain a target temperature and is a measure how fast the bulb filament is being cooled. So rather than an anemometer I decided to call it a coolometer. Unfortunately Futurama used that name first. Rather than displaying megafonzies mine displays milliwatts!

Quantifying cooling system – [Link]

Smart Battery Charger


gfwilliams @ instructables.com has build a smart battery charger that is able to individually charge each battery , automatically discharge them and give you an idea of their capacity. The charger is controlled by an Espruino Pico and results are displayed on a Nokia 5110 LCD display.

If you’re anything like me you’ll end up with a lot of rechargeable batteries, none of which end up being charged properly, and some of which turn out to be completely unusable. It’d be perfect if you had a low-power battery charger that you could leave on all the time, that would charge your batteries individually, automatically discharge them, and give you an idea of their real capacity. That’s what you’ll make in this tutorial!

Smart Battery Charger – [Link]

Quick Arduino Hygrometer with OLED display


jazzycamel @ instructables.com has published an Arduino based Hydrometer with OLED display. It uses an Arduino Leonardo Pro Micro, an Adafruit SSD1306 OLED display and DHT11 digital temperature and humidity sensor.

We have been having some condensation and mould issues in our apartment recently due to, I think, the humidity levels. Our property is relatively newly built and, as such, has very good insulation properties (double glazed windows etc.).

Quick Arduino Hygrometer with OLED display – [Link]

Starling – WiFi enabled LED Display


Starling is a modular, Open Source LED display with WiFi connectivity. It comes with a mobile app for easy configuration and usage and has hardware support for Bluetooth.

The LED matrix is driven by an Atmega8 microcontroller (MCU), instead of a standard ASIC. This provides a lot of flexibility in the firmware. The firmware detects and assigns IDs to newly plugged-in modules. The microcontroller also stores font tables; hence if ASCII is sent on the serial (UART) port of the MCU, ASCII is what will be displayed on the matrix. Since the firmware detects adjacent displays, it can easily decide if it needs to display static or scrolling text.

Starling – WiFi enabled LED Display – [Link]

OpenSource Arduino OLED Clock with temperature measurement


Konstantin Dimitrov has published his Arduino OLED clock which uses DS1307 real time clock module and TMP102 temperature sensor that communicate through I2C.

This clock will not only show you exact time and date but also it will show you the ambient temperature in both Fahrenheit and Celsius, with accuracy of 0.5°C (-25°C to +85°C) and with resolution of 0.0625°C. The pages are changing on every 10 seconds, but you can change that.

OpenSource Arduino OLED Clock with temperature measurement – [Link]

Wi-Fi and OLED Upgrade for MightyOhm Geiger Counter


Dan Watson @ syncchannel.blogspot.com wanted to have more fun with his MightyOhm Geiger Counter so decided to add an OLED display and Wifi capability to it. To achieve that he modified the counter, added a Feather HUZZAH ESP8266 with OLED FeatherWing and wrote some code. The process is documented on his blog:

I assembled my Geiger counter kit from MightyOhm some time ago. It’s a very fun kit and the finished counter looks awesome. Oh, that Geiger-Muller tube sitting on that yellow PCB! I’ve always wanted to modify it somehow and add functionality. Today I realized that an Adafruit Feather sits PERFECTLY where the AAA battery holder normally goes. Doesn’t it look like they belong together?
