Broadcom AFBR-S4N66C013 NUV-HD single silicon photo multiplier

Broadcom AFBR-S4N66C013 NUV-HD single silicon photo multiplier

989
Views
0 Comments

The Broadcom® AFBR-S4N66C013 is a single silicon photo multiplier (SiPM) used for ultra-sensitive precision measurement of single photons.

The active area is 6.14 × 6.14 mm2

Key features

  • High PDE of more than 55% at 420 nm
  • High fill factors
  • Excellent SPTR and CRT
  • Excellent uniformity of breakdown voltage

Additional features

High packing density of the single chips is achieved using through-silicon-via (TSV) technology. Larger areas can be covered by tiling multiple AFBR-S4N66C013 chips to an array almost without any edge losses. The protective layer is made by a glass highly transparent down to UV wavelengths, resulting in a broad response in the visible light spectrum with high sensitivity towards blue- and near-UV region of the light spectrum.

Features:

  • High PDE of more than 55% at 420 nm
  • High fill factors
  • Excellent SPTR and CRT
  • Excellent uniformity of breakdown voltage
  • Excellent uniformity of gain
  • With TSV technology (4-side tilable)
  • Size 6.14 × 6.14 mm2 n Cell pitch 30 × 30 μm2
  • Highly transparent glass protection layer
  • Operating temperature range from –40°C to +85°C
  • RoHS and REACH compliant

Applications

  • X-ray and gamma ray detection
  • Gamma ray spectroscopy
  • Safety and security
  • Nuclear medicine
  • Positron emission tomography
  • Life sciences n Flow cytometry
  • Fluorescence – luminescence measurements
  • Time correlated single photon counting
  • High energy physics
  • Astrophysics
