NE555 timer sparks low-cost voltage-to-frequency converter

NE555 timer sparks low-cost voltage-to-frequency converter

6700
Views
0 Comments

by Gyula Dioszegi @ edn.com:

In 1971, Signetics—later Philips—introduced the NE555 timer, and manufacturers are still producing more than 1 billion of them a year. By adding a few components to the NE555, you can build a simple voltage-to-frequency converter for less than 50 cents. The circuit contains a Miller integrator based on a TL071 along with an NE555 timer (Figure 1). The input voltage in this application ranges from 0 to –10V, yielding an output-frequency range of 0 to 1000 Hz. The current of C1 is the function of input voltage: IC=–VIN/(P1+R1).

NE555 timer sparks low-cost voltage-to-frequency converter – [Link]
