Binder Jetting vs CNC Machining: Which is Better for Rapid Prototype?

Binder Jetting vs CNC Machining: Which is Better for Rapid Prototype?

1.160
Views
0 Comments

Have you ever requested a third-party rapid prototyping services provider to fabricate samples for testing? If so, you were likely offered either 3D printing or CNC machining as options.

Sometimes customers have a difficult time trying to decide that prototyping method suits their manufacturing purposes better. This post provides an in-depth comparison of 3D printing, to be exact, binder jetting, and CNC machining. So that you can know for sure that will work better for you.

Types of Rapid Prototyping

Well, there are numerous types of rapid prototyping, all of which can be attributed to either subtractive manufacturing (SM) or additive manufacturing (AM) techniques. The first one implies that the material is cut out of a workpiece to achieve the design required.

The following manufacturing techniques are attributed to SM rapid prototyping:

  • CNC machining
  • Metal casting prototyping
  • Metal extrusion prototyping
  • Sheet metal prototyping

The second rapid prototyping technique is grounded on adding material layer by layer to achieve the design required or a similar principle. All such types are known as different 3D printing techniques. The following manufacturing types of 3D printing are attributed to AM rapid prototyping:

  • Binder Jetting
  • Selective Laser Sintering (SLS)
  • Fused Deposition Modeling (FDM)
  • Stereolithography (SLA)
  • Multi Jet Fusion (MJF)
  • Injection Molding
  • Injection molding

As you may see, the number of rapid prototyping options available is extensive. To help you not to get lost in what to choose, we detail the essential aspects of metal machining and the popular 3D printing technique – binder jetting below.

Binder Jetting

Definition

Binder Jetting is an AM technique that is based on creating a 3-dimensional object layer by layer in accordance with a computer-aided design (CAD) file.

The principle of binder jetting is the use of the metal powder material that is solidified with a binding agent layer by layer. First, a piston of a binder jetting machine ensures that the powder is compressed dense enough for binding. Then, powder in the build box is cured with a binding liquid forming a solid shape. Then, with the use of brushes and air blowers, the excess powder is removed.

After the binder jetting is finished, simple post-production procedures are needed. The printed parts are separated from build boxes, cleaned, and bead blasted. You may also perform additional finishing techniques to enhance the properties of parts printed using binder jetting.

Pros and Cons

Here’s the list of the main strengths of binder jetting as a particular method of 3D printing:

  • One of the quickest rapid prototyping processes overall
  • Complete design freedom
  • Minimal material wastage
  • Simple, single-step manufacture
  • Cost-effective process
  • High accessibility of binder jetting machines, spare parts, and printing materials
  • Environment-friendly
  • Safe for labor

And the notable weaknesses of the process:

  • Limited range of materials available
  • Limited dimensions of components that are possible to print
  • Require post-processing, but some techniques still do not enable good surface finishing
  • The structure of printed components typically makes prototypes unsuitable for physical properties testing

Application

This AM technique is widespread in the following industries:

  • Architecture and construction
  • Maritime industry
  • Healthcare
  • Chemical industry
  • Mechanics
  • Food processing industry
  • Aeronautics
  • High-tech
  • Retail
  • Automotive
  • Textile and fashion
  • Robotics
  • Optics
  • Electronics
  • And many others

3D printing enthusiasts use binder jetting to replace literally any goods that can only be printed. The capabilities of binder jetting are limited only with the phantasy of such equipment unit’s owners. Still, binder jetting has even wider industrial use for the production of goods.

Precision sensor probe inspection of gear. Quality control in metalwork. Metrology system for gear

CNC Machining

Definition

CNC machining is an SM technique based on creating a 3-dimensional object by cutting out pieces of material of a workpiece according to a G-coded CAD file. The range of machining operations that can be done using multiple CNC machines is vast and include the following:

  • Drilling
  • Milling
  • Boring
  • Facing
  • Planing
  • Sawing
  • Broaching
  • Reaming
  • Turning
  • And others

Machines that perform CNC machining are automated, computer-driven centers with spindles that hold cutting tools and move along multiple (4,5,6, and even more) dimensions. They cut metal chips off workpieces’ surfaces, ensuring high dimension accuracy.

CNC machines are named after the process they intended to perform (although advanced centers employ multiple operations). This list includes mills, routers, drills, lathes, turning machines, etc.

Pros and Cons

Here’s the list of the main strengths of CNC machining:

  • Continuous use of machines without labor involvement
  • Consistency from batch to batch
  • Great dimensional accuracy and precision
  • High quality of the surface
  • Components machined are fully suitable for properties testing
  • Cost-effective process, but only if a significant number of products is machined
  • Good design freedom
  • A vast range of materials is supported

And the notable weaknesses of the process:

  • Time-consuming process
  • Demanding to the expertise of the labor
  • Not always ensure single-step manufacture
  • Machines are difficult in maintenance and adjustment
  • Material wastage
  • May not be environment-friendly
  • Is dangerous for labor unless safety measures are taken

Application

Decades ago, manual machining was a prevalent method of fabrication. It is not surprising that in the following contemporary industries, CNC machining is the common manufacturing technique for rapid prototyping as well:

  • Architecture and construction
  • Healthcare and pharmacy
  • Food processing industry
  • High-tech
  • Automotive
  • Robotics
  • Optics
  • Electronics
  • Military and defense
  • Aerospace
  • Transportation
  • Oil and Gas
  • And nearly any other somewhat

CNC machining utilizes fully automated centers that employ subtractive machining to fabricate components. Rapid prototyping with the use of CNC equipment units is highly common and regarded as a great way to produce samples for testing.

Differences Between Binder Jetting and CNC Machining

Regarding the essential differences between these two manufacturing processes, all existing ones are detailed in the table below.

Factor Binder Jetting CNC Machining
Principle of functioning Additive machining Subtractive machining
Type of files required CAD files G-coded CAD files
Parts’ dimensions supported Strictly limited. Depends on the type of binder jetting machine. Almost unlimited. Depends on the method of metal machining and the type of CNC unit used.
Material availability A limited range. Each method has its own small range of materials supported. A vast range. Almost unlimited, depending on the method of metal machining and the CNC unit used.
Speed of prototyping A single unit ensures end-to-end performance. Speed depends on the design.

A single prototype can be produced quickly.

Several units may be involved in the end-to-end performance. Speed depends on the design and the number of CNC units.

A single prototype can be produced slowly.

Accuracy / Precision Good dimension accuracy. Superior dimensional accuracy.
Repeatability / Consistency Consistency may vary from batch to batch. Ensures a high batch-to-batch consistency.
Surface quality Appropriate surface quality. In some cases, additional finishing processes may not be applicable. Surface quality depends on the method of metal machining and the type of CNC unit used. Generally, surface quality is high. Suitable for the additional finishing process.
Adherence to physical properties of the intended component. Generally unusable to produce components for further physical and chemical properties of components testing. Exception – when large-scale manufacturing is 3D printing (binder jetting)-based. Depending on the manufacturing method employed, it is generally usable to produce components for further physical and chemical properties of components testing.
Complexity of use Comparatively simple process. Does not require specialized knowledge. Comparatively complicated process. Require a highly professional team of specialists to run.
Flexibility Highly flexible process. Nearly any design can be created using a single equipment unit. Less flexible process. Most designs can be created, depending on the method. May require the use of multiple equipment units.
Cost Low to medium price range, depending on the process and the material. Medium, to high price range, depending on the process and the material.
Material wastage Produce nearly no material wastage. Is typically associated with high material wastage.

In this comparison, a winner cannot be determined. Depending on your exact needs, materials, requirements to a prototype, timelines, and other factors, you may find any of the techniques being completely applicable.

Final Word

CNC machining is a costly and not that quick technique for fabricating durable prototypes of workpieces. It is great for testing manufacturing techniques and the physical properties of samples.

In contrast, binder jetting is indeed a rapid and cost-effective additive manufacturing prototyping technique. It is great for taking a quick look at newly modeled designs or producing cheap samples for presenting stakeholders. You should guide your decisions based on careful consideration of the factors specified in this post.
